Introduction

   The JHBF SFP+ is designed for the high-speed and bidirectional telecommunication system,

   supporting any data rates 10G ~25 Gbit/s, and the transmission distance is up to 120 km. The

   JHBF SFP series optical transceiver is designed by all metal case and standard LC interface,

   and have good EMI and ESD performance. It also supports Class 1 laser product safety standards.

   Moreover, JSP series optical transceiver complies with ITU-T and IEEE standards and Multi Source

   Agreement (MSA).  It can be    directly applied to telecommunication equipment of Cisco, H3C, Huawei,

   and other manufactures. This series of SFP is widely used in the network of carrier and data center.

   Features

       Support any rate from 10G~25G, include STM16/STM64, FC2/4/8/16, CPRI option 3/4/5/6/7/8/9/10,

      OTU1/OTU2, 10GE/25GE.

Compliant to SFP MSA, ITU-T and IEEE standard.

Compatible to multi manufacturer equipment, such as Cisco, Juniper, H3C, Huawei and so on.

Fully RoHS Compliant.

Standard LC connector.

Very low EMI and excellent ESD protection.

Low power consumption.

Provide more powerful monitoring functions (DDM follows the SFF-8472 protocol).

Meet the operating temperature range of commercial and industrial.

Support the Class 1 laser product safety standards (IEC 60825-1and IEC 60825-2).

   Application

Ethernet(10GBASE-SR/SW,10GBASE-LR/LW,10GBASE-ER/EW,10GBASE-ZR/ZW)

SDH /SONET(STM-64/16)

CPRI/OBSAI for Mobile Fronthaul(CPRI option3/4/5/6/7/8/9/10)

Fiber channel (FC2/4/8/10)

Others optical links (any 10G~2.5Gbps).
