Crispy Corn Puff Snack Extruder Machine / Puffed Snack Production Line / corn stick extruder food extruder

1.Corn stick extruder food extruder Puffed Snack Production Line Description:

    Puffed leisure Food production line can do the works of raw materials preparation, extrusion, core filling, shaping,cutting,coating and flavoring at a time, which is high automation degree.

This production line has the advantages of more machines choice,flexible and diverse configurations,

wide range of raw materials application, numerous in products variety and easy operation. It can make the puffed food, such as core filling snack food, filling biscuit, nutrition breakfast, corn flakes etc. After being puffed, the products are crispy, easy to digest and unique taste. They are the perfect leisure food for consumers.You just need to change different shapes of die in the outlet of extruder machine. Then you could get various shapes of puffs snack.

2.Main Features:
1).Our processing line adopt international advanced technology, the pellets size are very even.
2).we can adjust the cutter speed and the dies to get the different diameter and the length product
3).The Electric heating device system can control the temperature accurately
4).High temperature and high pressure can kill the salmonellosis andbacterial infections.



3. Products:

Mixing system---Extrusion system----Drying system----Flavoring system--Packing system

4.Technical Parameter:

Model	SLG65-III	SLG70-III	SLG85-III
Install Power	76KW	95kw	178kw
Power Consumption	54KW	66kw	125kw
Capacity	120-150KG/H	240-260kg/h	300-500kg/h
Dimension	17×2×2.5m	22×2×2.5m	26×2×3.5m



5.Main equipment of Crispy Corn Puff Snack Extruder Machine:

Mixer→screw conveyor→twin screw extruder→air conveyor→dryer→hoister→flavoring drum and oil sprayer→cooling machine→packing machine.

	Name Mixer Usage To mix the raw materials evenly, fast speed, no leakage.   Type including Single axle and double shaft mixer Motor 3kw, 4kw, 7.5kw etc. Capacity 20kg/time, 50kg/time, 100kg/time, 200kg/time, 500kg/time etc. Material stainless steel, carbon steel
	Name Twin screw extruder Usage To extrude the raw materials and make them to the required shape and size of the snack food pellets by mould model SLG65, 70, 75, 85 Motor 22kw, 30kw, 55kw, 75kw, 90kw, 110kw etc. Capacity 100kg/h to 0.5 ton/h Material Screw materials 38CrMoAl stainless steel, carbon steel
	Name Dryer (oven) Usage the expanded food go through the "s" passage, to be dried to increase the self life. Type electrical, steam, gas fired, diesel fired heating type Motor KX-3-5, KX-5-5, KX-5-8, KX-5-10, KX-7-10 etc. Capacity 100kg/h to 10 ton/h Material stainless steel, carbon steel
	Name Flavoring machine Usage To mix the oil and flavors on the surface of the snacks food Type single and double flavoring drum Motor 0.75kw Capacity 100kg/h to 10 ton/h Material stainless steel
	Name Packaging machine Usage To pack the snack food with required weight Flowing Process Manual Bag placing→Automatic filling→Automatic weighing→ Automatic bag conveyor→Automatic bag sewing or heat sealing Weight range 1-5kg/bag, 5-25kg/bag, 25-50kg/bag Material stainless steel, carbon steel Type Automatic

1.  Pre-sale services:

 Act as a good adviser and assistant of clients, enable them to get rich and generous returns on their investments.

1.. Select equipment model;

2.. Design and manufacture products according to clients' special requirement;

3.. Train technical personnel for clients.

2.  Services during the sale:

Respect clients, devote ourselves to improving the total value of clients.

1.. Pre-check and accept products ahead of delivery;

2.. Help clients to draft solving plans.

3. After-sale services:

Provide considerate services to minimize clients' worries.

1.. Assist clients to prepare for the first construction scheme;

2.. Install and debug the equipment;

3.. Train the first-line operators;

4.. Examine the equipment;

5.. Take initiative to eliminate the troubles rapidly;

6.. Provide perfect service;

7.. Provide technical exchanging.

1. Daub coal oil on the surface of the Maize Puff Corn Rice Snacks Food Making Machine.

2. Plastic film as the inner packing.

3. Standard export wooden case as the outer packing.

4. Train, ship or depend on clients' requirement

     Jinan FLD Machinery Co., Ltd.is a professional food machinery manufacturer in Jinan city shandong province China.Our company congregates an exceptional food machine engineering team, personal customer service center and highquality manufacturing capabilities have evolved exponentially,We are working hard on explore constantly not only in the research of extrusion technology, but also in food technics to benefit our clients producing newfangled food in their markets. It making us become one of the preeminent providers of reliable extrusion equipment world-wide.

We have through the years established good working relationship with some reputable organizations both at home and abroad with outstanding goodwill. We have a group of experienced experts and outstanding engineers who do provide the professional service delivery and installation. Based on the clients specific requirement, we also design and produce the machines to order.

 Q: How long is your delivery time?

 A: Generally speaking, it is 20 days if the machines are in stock. Or it is 25 days if the

goods are out of stock.

Q: Could you supply all the parameters about the machines?
A: Of couse. We are delighted to supply all the informtion that you want to know.

Q: How about the after sale service?
A:  We will send our engineers to your factory for installation and training.
