Corn Puffed Food Snacks Making Machine Extrusion Corn Stick Production Line with 1

1.Corn Puffed Food Snacks Making Machine Extrusion Corn Stick Production Line Description:

     Corn puff snacks food machine is a new type of extruding food machine studied and developed by ourselves on the basis of learning from advanced technology in the world so that its technical performance and quality of products both reach to the most advanced in the world. This line will finish mixing, extruding, cutting, spraying, and producing in onepass operation automatically. This has features of lots of types, flexible collocation, extensive applied materials, various products and easy operation.

Variety shapes are available for ball, tube, stick, ring, fruit loop, star, wheel and flower and heart shape by adjusting the mould in the extruder

2.Main Features:
1) Simple structure in linear type ,easy in installation and maintation.
2) Adopting advanced world famous brand components in pneumatic parts ,electric parts and operation parts.
3) High pressure double crank to control the die opening and closing.
4) Running in a high automatization and intellectualization,no pollution
5) Apply a linker to connect with the air conveyor ,which can directly inline with filling machine .



3. Corn Puffed Food Snacks Making Machine Corn Stick Production Line Products:

Mixing system---Extrusion system----Drying system----Flavoring system--Packing system



4.Technical Parameter:

Model	SLG65-III	SLG70-III	SLG85-III
Install Power	76KW	95kw	178kw
Power Consumption	54KW	66kw	125kw
Capacity	120-150KG/H	240-260kg/h	300-500kg/h
Dimension	17×2×2.5m	22×2×2.5m	26×2×3.5m



5.Main equipment of Corn Snacks Extrusion Corn Strips Stick Production Line:

Mixer→screw conveyor→twin screw extruder→air conveyor→dryer→hoister→flavoring drum and oil sprayer→cooling machine→packing machine.

	Name Mixer Usage To mix the raw materials evenly, fast speed, no leakage.   Type including Single axle and double shaft mixer Motor 3kw, 4kw, 7.5kw etc. Capacity 20kg/time, 50kg/time, 100kg/time, 200kg/time, 500kg/time etc. Material stainless steel, carbon steel
	Name Twin screw extruder Usage To extrude the raw materials and make them to the required shape and size of the snack food pellets by mould model SLG65, 70, 75, 85 Motor 22kw, 30kw, 55kw, 75kw, 90kw, 110kw etc. Capacity 100kg/h to 0.5 ton/h Material Screw materials 38CrMoAl stainless steel, carbon steel
	Name Dryer (oven) Usage the expanded food go through the "s" passage, to be dried to increase the self life. Type electrical, steam, gas fired, diesel fired heating type Motor KX-3-5, KX-5-5, KX-5-8, KX-5-10, KX-7-10 etc. Capacity 100kg/h to 10 ton/h Material stainless steel, carbon steel
	Name Flavoring machine Usage To mix the oil and flavors on the surface of the snacks food Type single and double flavoring drum Motor 0.75kw Capacity 100kg/h to 10 ton/h Material stainless steel
	Name Packaging machine Usage To pack the snack food with required weight Flowing Process Manual Bag placing→Automatic filling→Automatic weighing→ Automatic bag conveyor→Automatic bag sewing or heat sealing Weight range 1-5kg/bag, 5-25kg/bag, 25-50kg/bag Material stainless steel, carbon steel Type Automatic

a. We can keep product design in the same level with internationally advanced technology consistently.

b. We have high diathesis staff and excellent processing equipment, and quality control runs through the whole production process from parts stock to the beginning of production.

c. We can guarantee customers superior quality machines up to design requirements and perfect working state.

d. Our technicians can also provide all kinds of relevant technology to make the food production clean, healthy and safe.

e. We will dispatch our technicians to your factory to guide you installation and commissioning work and training your operator.

f. We provide 1 year complete Guarantee and life-time maintenance service.

1. Daub coal oil on the surface of the machines.

2. Plastic film as the inner packing.

3. Standard export wooden case as the outer packing.

4. Train, ship or depend on clients' requirement

     Jinan FLD Machinery Co., Ltd.is a professional food machinery manufacturer in Jinan city shandong province China.Our company congregates an exceptional food machine engineering team, personal customer service center and highquality manufacturing capabilities have evolved exponentially,We are working hard on explore constantly not only in the research of extrusion technology, but also in food technics to benefit our clients producing newfangled food in their markets. It making us become one of the preeminent providers of reliable extrusion equipment world-wide.

We have through the years established good working relationship with some reputable organizations both at home and abroad with outstanding goodwill. We have a group of experienced experts and outstanding engineers who do provide the professional service delivery and installation. Based on the clients specific requirement, we also design and produce the machines to order.

 Q: How long is your delivery timre?

 A: Generally speaking, it is 20 days if the machines are in stock. Or it is 25 days if the

goods are out of stock.

Q: Could you supply all the parameters about the machines?
A: Of couse. We are delighted to supply all the informtion that you want to know.

Q: How about the after sale service?
A:  We will send our engineers to your factory for installation and training.

Contact with us:

If you have any questions about Corn Puffed Food Snacks Making Machine, don't hesitate to contact with us
