Decilious Puffing Machine Rice Corn Puff Making Machines Stainless Steel Automatic

1.Snack food extruder puffing machine rice corn puff making machines Description:

1. Small Corn Puffed Snack Extruder Machine Expand Corn Snacks Food Extruder Production Line is widly used for producing corn snacks, corn puffs, nutrition powder, cereal bar, breakfast cereal, chocolate filled snack etc. In extruder, the ingredients are cooked under intense heat and pressure as it moves toward the open end of the extruder where ingredients pass through a shaping die and knife.
2. Small Corn Puff Snack Extruder Machine maize snacks food production line adopts corn flour,rice powder, wheat flour etc as raw materials
3. Different shapes can be made by adjusting the dies from extruder
4. Output can be 150kg/h, 250kg/h, 450kg/h
5.Voltage in China: Three phases: 380V/50Hz, Single phase: 220V/50Hz, we can make it according to customers' Local voltage according to different countries
6.All the machines are made by stainless steel, this line is with reasonable design and with high automation; the screws are made by alloy steel, with building block system structure and self-cleaning function.

2.Expand Corn Snacks Food Machinery Production Line  Main Features:

1) Simple structure in linear type ,easy in installation and maintation.

2) Adopting advanced world famous brand components in pneumatic parts ,electric parts and operation parts.

3) High pressure double crank to control the die opening and closing.

4) Running in a high automatization and intellectualization,no pollution

5) Apply a linker to connect with the air conveyor ,which can directly inline with filling machine .



3.Puffed snack food extruder making machine Products:

Mixing system---Extrusion system----Drying system----Flavoring system--Packing system



4.Technical Parameter:

Model	SLG65-III	SLG70-III	SLG85-III
Install Power	76KW	95kw	178kw
Power Consumption	54KW	66kw	125kw
Capacity	120-150KG/H	240-260kg/h	300-500kg/h
Dimension	17×2×2.5m	22×2×2.5m	26×2×3.5m



5.Main equipment of Corn puff snack extruder machine:

Mixer→screw conveyor→twin screw extruder→air conveyor→dryer→hoister→flavoring drum and oil sprayer→cooling machine→packing machine.

	Name Mixer Usage To mix the raw materials evenly, fast speed, no leakage.   Type including Single axle and double shaft mixer Motor 3kw, 4kw, 7.5kw etc. Capacity 20kg/time, 50kg/time, 100kg/time, 200kg/time, 500kg/time etc. Material stainless steel, carbon steel
	Name Twin screw extruder Usage To extrude the raw materials and make them to the required shape and size of the snack food pellets by mould model SLG65, 70, 75,85 Motor 22kw, 30kw, 55kw, 75kw, 90kw, 110kw etc. Capacity 100kg/h to 0.5 ton/h Material Screw materials 38CrMoAl stainless steel, carbon steel
	Name Dryer (oven) Usage the expanded food go through the "s" passage, to be dried to increase the self life. Type electrical, steam, gas fired, diesel fired heating type Motor KX-3-5, KX-5-5, KX-5-8, KX-5-10, KX-7-10 etc. Capacity 100kg/h to 10 ton/h Material stainless steel, carbon steel
	Name Flavoring machine Usage To mix the oil and flavors on the surface of the snacks food Type single and double flavoring drum Motor 0.75kw Capacity 100kg/h to 10 ton/h Material stainless steel
	Name Packaging machine Usage To pack the snack food with required weight Flowing Process Manual Bag placing→Automatic filling→Automatic weighing→ Automatic bag conveyor→Automatic bag sewing or heat sealing Weight range 1-5kg/bag, 5-25kg/bag, 25-50kg/bag Material stainless steel, carbon steel Type Automatic

1. Consultation service before, during,and after sales;

2. Project planning and design service;

3. Debugging of equipment until everything is functional;

4. Management of equipments' long distance shipping from seller's factory to the named place by buyer;

5. Training of equipment maintenance and operating personally;

6. New production techniques and formulas;

7. Provide 1 year complete warranty and life-time maintenance service

A. We will pack all necessary machines into wooden cases. For drying machine, and heavy extruders, we will fix them in the container with very strong iron wire.

B. If by LCL for small quantity machines, we will let send to QINGDAO port for loading.

C. If need containers, our trucks will take the containers from port to our factory for professional and safely loading, and then return to port for shipment.

Jinan FLD Machinery Co., Ltd.is a professional food machinery manufacturer in Jinan city shandong province China.Our company congregates an exceptional food machine engineering team, personal customer service center and highquality manufacturing capabilities have evolved exponentially,We are working hard on explore constantly not only in the research of extrusion technology, but also in food technics to benefit our clients producing newfangled food in their markets. It making us become one of the preeminent providers of reliable extrusion equipment world-wide.

We have through the years established good working relationship with some reputable organizations both at home and abroad with outstanding goodwill.We have a group of experienced experts and outstanding engineers who do provide the professional service delivery and installation. Based on the clients specific requirement, we also design and produce the machines to order.
