11000 Bags Full Automatic Instant Noodle Production Line with FUJI Electric Parts

The stainless steel instant noodle production line is automatically completed from flour to finished product, with simple operation, novel design, moderate output, small footprint, low investment and quick results. The full automatic instant noodle machine can produce round or square instant noodles. The fried instant noodles produced have short re-hydration time, good elasticity, smoothness and transparency, and are comparable to large-scale equipment popular in the market.

1. Raw Materials: Wheat Flour
2. Products: Instant Noodle
3. Capacity: 11000PCS/8H
4. Low Fat Instant Noodle Fast Food Cooking Equipment Flow Chart: Mixing -Shaping -Boiling -Frying-Cutting -Cooling
5. Voltage:380V/50HZ/Three Phase, 220V/50HZ/Single Phase or Change As Required
6. Machines Materials: All the machines are made by food grade stainless steel.

1. Mixer / Dough maker

The main function of Flour Mixer is to mix flour, salt, alkali, water and other additives evenly, this is the first step of instant noodle producing.
Technical parameter:
Power: 3 KW
Capacity: 50 kg/time
Dimension:1100×650×800 mm

2. Double pressing shaper

1.  This equipment consists of five pairs of down rollers and wave formers.
2. Function: press the mixed raw material to belt shape, and roller pressing the belt make it thinner, at last a cutting knife will cut it to strips and the wave former will make wave shape on each strip.
3.  The speed of this equipment is adjusted by a transducer which is easy to control and operate.

3. Boiling Machine

1. This equipment consists of body frame, boiling cases, conveying belt and steam pipelines.
2. Wave shaped noodle strips will be cooked by the steam when it goes through the case and it will have the strength and transparency characteristic after boiling.
3. The speed is adjustable which can be compatible with the Pressing shaper

Frying machine

1. This equipment consists of stainless frame, oil container, heat exchanger, driving part, fried shaping case and shaper part.
2. The main function of this equipment is to fry the boiled noodle and dehydrate it, after the frying, the noodle pieces will become square shape or round shape, each piece will be identical.

Cooling machine

This equipment consists of body frame, cooling machine and conveying bet, its duty is to cool the fried noodle piece rapidly.
Technical parameter:
Conveying speed: auto shift gears

Mixer→Roller Pressing Machine→Steaming Oven→Cutting Machine→Shaper→Fryer→Cooling Conveyor→Packing Machine

Packing:Inside: plastic bag.

Outside: wooden case (adopt the wooden case or wooden pellets depended on clients' requirement).

Transportation:Shipping, train, express, or upon clients' demands.

1. Are you intant noodle making machine manufacturer or trader?
 A: Certainly we are instant noodle making machine manufacturer. Welcome to visit us to check it !

2. Do you supply formula of instant noodle made by extruder to buyers?
 A: Yes, we supply free formula to buyers.

3. What kind of fuels we can choose during the production?
A: You can choose gas, diesel, electricity, steam as fuels, but please tell us when you ask for quotation.

4. How much area the whole making machine production line needs?
A: The best way is telling us your workshop area, then we will draw a draft for you to ensure the  rational use of your space.

5. If the power supply is not 3ph 380V 50HZ, could you offer the suitable machine?
A: Yes, we can offer the suitable machine according to your power supply, for example 3ph 380V 60HZ, 3ph 415V 60 HZ, 3ph 220V 60HZ and so on.
