FDA Industrial Food Grade Metal Detector Tunnel Dimension 50 X 25 Cm

Introduction

Advanced technique of electrical & mechanism designs is adopted for EJH series digital intelligent auto-conveying metal detector which have reasonable structure, beautiful appearance, highly detection sensitivity and stable behaviors. It is characterized by high detecting sensitivity and stable & reliable performance.
Comparing with traditional simulation detector , the function is more complete , the capability is more stable and dependable. It accord with the demand of certification-HACCP, QS, ISO9001, FDA.

Feature

Non-ferrous:1.0mm diameter ball

SUS: 1.2 mm diameter ball
Alarm: Audible and visual with automatic stop can install with the auto-rejection equipment according customer’s requirement.
Power: AC110V/220V/380V 50/60Hz.

Table of Sensitivity

Remark: the above data is empty machine sensitivity. The real sensitivity will be lower on condition of different products being tested.

Way of alarming: sound and light alarm, stop running automatically.

Performance

Detection style: digital intelligent with LCD display
Language : English,
Motor power: 200w/400w
The main material: SUS 304
Speed of transmission: 18-40 meter/minute
height of inspection window(cm):10
width of inspection window(cm):40

Highest Sensitivity: Ferrous 0.5mm diameter ball
