Parameter | Data |
Label Specification | Adhesive sticker,transparent or opaque |
Labeling Tolerance | ±0.5mm |
Capacity(pcs/min) | 40~120 |
Suit bottle size(mm) | L:40~400 W:20~200 H:0.2~150;Can be customized |
Suit label size(mm) | L:15-100;W(H):15-130 |
Machine Size(L*W*H) | ≈2080*695*1390(mm) |
Pack Size(L*W*H) | ≈2130*730*1450(mm) |
Voltage | 220V/50(60)HZ;Can be customized |
Power | 820W |
N.W(KG) | ≈200.0 |
G.W(KG) | ≈365.0 |
Label Roll | ID:Ø76mm; OD:≤260mm |
No. | Structure | Function |
1 | Conveyor | Transmit product |
2 | Labeling Head | Core of the labeler,including label-winding and driving structure |
3 | Touch Screen | Operation and setting parameters |
4 | Collection Plate | Collect the labeled products |
5 | Strengthening Sponge Roller | Press labeled product to strengthen labeling |
6 | Main Switch | Open the machine |
7 | Emergency Stop | Stop the machine if it runs wrong |
8 | Electric Box | Place electronic configurations |
9 | Pagination Device | Separate a stack of pouches/cards/...and feed to the conveyor one by one. |
