Food And Water Injection Or Oil Set Quantitative Pumping Machine

Name: Food And Water Injection Or Oil Set Quantitative Pumping Machine
Brand: Anhui Ruiling Meter Manufacturing Co., Ltd.

Price Negotiable

Price: $750.00(1 - 9 Cartons) $660.00(>=10 Cartons)

MOQ: 1 Carton

Delivery Time: Negotiable

Brand: FIMEET

Product Description

Product Application

Owns many patents, which is developed by Anhui ruiling meter manufacturing co.,ltd. This model of oil filling machine is widely used in industrial and mining enterprises, middle and small oil depot, gas station for transporting diesel and kerosene etc. This Anti- Explosion oil filling machine owns many advantages, for instance, reasonable design, compact structure, small and fine, convenient for carry, high accuracy, big flow rate convenient for usage, easy for maintenance, and so on.
Our design is much more compact, layout is more reasonable,increasing the operation efficiency.

SPECIFICATIONS FOR EDIBLE OIL FILLING MACHINE
Model No.:	BJJ-20-A9	Accuracy:	±0.5%
Flow range:	(1-45)L/min	Max.pressure:	4 Bar
Voltage:	AC 220v	Single Range:	0.0-99999.9L
Suction/Lift:	5m/10m	Accumulative Range:	0-99999L
Total weight:	60kg	Range of Price:	0.00-$99.99
Temperature range:	-20°c-50°c	Total Amount Range:	0-$99999
Inhalation caliber:	25mm	Measure Minimum:	5L
Discharge caliber:	20mm	Size:	600435410mm
Medium	Vinegar, Milking, Beer, Butter and other liquid.

Main Features

For the reason that our First generation mechanical oil filling machine has been copied, our company updated the products series with 10 updated points under the price not increased.

1. More attracting appearance;
2. Increasing the thickness of the shell;
3. Good at Resistant high temperature: 50℃ Test;
4. With functions of integer and non integer quantitative refueling;

5.The standard of excellent accuracy measuring accuracy can reach 0.5%;
6. Professional All of our oil filling machine are Anti-Corrosion type design;
7. Two way control valves to ensure the precise control of a small amount of fuel;

8. Our design is much compact, layout is more reasonable, increasing the operation efficiency;
9. With Double-layer steel wire mesh, wear-resisting, corrosion resistance, pressure resistant tubing;
10. Choosing new type electromagnetic switch,greatly enlarging using safety and stability and prolong the using life.

Detailed Images

Machine Parts

Name: Water dispenser

Brand: Zhunde;

Quantitative and non-quantitative annotation can be realized

Machine Parts

AC Power Button;

All English Panel;

Show Unit Price and Total Volume.

Machine Parts

Big screen display, number button

Machine Parts

Printer can be installed (sales receipt)

Standard Configuration

1 Set Manual;

2M Inlet Pipe;

6M Output Pipe;

1 Set 11A Automatic Fuel Nozzle.

Packing & Delivery

Packaging
Size	75 * 65 * 60 CM
Weight	60 KG
Packaging Details	The normal package is wooden box(Size: LWH). If export to European countries,the wooden box will be fumigated. Package also can according to customer special requirements.

By Sea	Delivery from Any seaport of China if customer has special requirements
By Air	Departure from Any Airport of China if customer has special requirements
By Express	By any Express of China if customer has special requirements

Payment

Payment Term	T/T	EXW	100% T/T in advance
				FOB	30% T/T in advance, paid the balance before shipment
				CFR	30% T/T in advance, paid the balance against copy of B/L
				CIF	30% T/T in advance, paid the balance against copy of B/L
		L/C	L/C amount above 10,000 usd, we can accept L/C at sight
		West Union	Amount lower than 5000 usd
Delivery Time	7~10 working days after receiving payment for one container

We welcome use Trade Assurance, you'll enjoy:

100% Product quality protection;
100% On-time shipment protection;
100% Payment protection for your covered amount.
