4x2.5 ExactCables FPLR Type Fire Alarm Rated Cable Shielded with Bare Copper Wire
Price:
$0.05/meters >=10000 meters
MOQ:
10000 meters
Delivery Time:
Negotiable
Brand:
ExactCables
Product Description
Product Description
Type | Fire Alarm Cable |
Place of Origin | ZHEJIANG |
Brand Name | ExactCables |
Shield | Al/Foil |
Specification | 2 x 1.5mm2 |
Wire Core Material | Bare Copper Wire |
Cable Core | 2cores |
Drain Wire | 1/0.5tc mm |
Certification | CE, RoHS, CCC, 1424 LPCB |
Transport Package | Shipping Box or Wooden Pallet |
PRODUCT DESCRIPTION:
* Cables symmetrical,twisted pair,with single copper conductor cross-section from 0,2 to 2,5mm², with the isolation of fire-resistant silicone rubber sheathed in PVC low flammability with low smoke and gas evolution.The shell is orange.
* Designed for group use,fixed installations in fire protection systems,including fire alarm systems,warning systems and evacuation,automatic fire extinguishing systems,smoke protection systems,as well as in other important life-support systems,which should keep working in a fire;used indoors and out doors.
* Cables KPSng-FRLS should have a low smoke and gas evolution,having a class of fire danger P1.1.2.2.2 in accordance with Russian standards R 53315-2009.Cables must meet the regulatory requirements of the Technical Regulations on fire safety,including established in Russian standard R 53315-2009 p.5.3 PRGP1 (category A combustion-proliferation group laying) p.5.8 to 1(fire-resistance for 180 minutes).
* Cables symmetrical,twisted pair,with single copper conductor cross-section from 0,2 to 2,5mm², with the isolation of fire-resistant silicone rubber sheathed in PVC low flammability with low smoke and gas evolution.The shell is orange.
* Designed for group use,fixed installations in fire protection systems,including fire alarm systems,warning systems and evacuation,automatic fire extinguishing systems,smoke protection systems,as well as in other important life-support systems,which should keep working in a fire;used indoors and out doors.
* Cables KPSng-FRLS should have a low smoke and gas evolution,having a class of fire danger P1.1.2.2.2 in accordance with Russian standards R 53315-2009.Cables must meet the regulatory requirements of the Technical Regulations on fire safety,including established in Russian standard R 53315-2009 p.5.3 PRGP1 (category A combustion-proliferation group laying) p.5.8 to 1(fire-resistance for 180 minutes).
Specification
Part N0. | Description | Conductor Spec. | Insulation | Jacket | |||||
Nom Thick. (mm) | Nom Diam (mm) | Nom Thick. (mm) | Nom Diam (mm) | ||||||
ECFC001 | 2×0.50mm2 | 0.5 | 1.8 | 0.7 | 5.2 | ||||
ECFC002 | 3×0.50mm2 | 0.5 | 1.8 | 0.7 | 5.2 | ||||
ECFC003 | 2×0.80mm2 | 0.5 | 2 | 0.7 | 5.4 | ||||
ECFC004 | BC/TC | 3×0.80mm2 | 0.5 | 2 | 0.7 | 5.4 | |||
ECFC005 | PVC or LSOH | 2×1.00mm2 | 0.6 | 2.35 | 0.8 | 6.5 | |||
ECFC006 | Insulation Jacket | 3×1.00mm2 | 0.6 | 2.35 | 0.8 | 6.5 | |||
ECFC007 | 2×1.50mm2 | 0.7 | 2.8 | 1 | 7.8 | ||||
ECFC008 | 3×1.50mm2 | 0.7 | 2.8 | 1 | 7.8 | ||||
ECFC009 | 2×2.50mm2 | 0.8 | 3.4 | 1 | 9 | ||||
ECFC010 | 3×2.50mm2 | 0.8 | 3.4 | 1 | 9 | ||||
Why Choose Us
We,Ningbo Exact Cables & Wire Co.,Ltd is a Pioneer manufacturer with more than 12 years experience in the cable industry in China.We can professionally manufacture and supply Fire alarm cables, Alarm/security cables, Speaker cables, Coaxial cables, Datacables, HDMI cables, Telecommunication cables, Telephone cables, Power cables ,accessory and other various of cables and wires.Our products with the brand of "Exactcables" which are approved by China CCC, the CPR, UL, CE, RoHS, ETL and REACH. The current productioncapacity is about 500,000,000 meters per year.
