Pyrolysis Machines for Converting Small Waste Plastic to Diesel Fuel Oil 380V Voltage
Small Waste Plastic Tyre convert to Diesel Fuel Oil Pyrolysis Machines Plant Free Installation
Model of waste tire pyrolysis oil plant:
| Model | Reactor size | Material | Handling capacity/batch | Seaworthy packing |
| LJ-8 | 2200*6000mm | Q245R /Q345R boiler steel ,16mm thickness | 5 tons | 2*40HQ |
| LJ-9 | 2200*6600mm | 8tons | ||
| LJ-10 | 2600*6600mm | 10tons | 1*40FR+1*40HQ | |
| LJ-12 | 2800*6600mm | Q245R/Q345R boiler steel ,18mm thickness | 12tons | |
| LJ-15 | 2800*7700mm | 15tons |
Working process of Old Tire Recycle To Oil Pyrolysis Machine Fuel Oil Refining:
First, the scrap tyres are put into the reactor, and then seal the feeding in door, later start the machine and the reactor will be rotating and heated by coal, natural gas, wood or electricity. When the temperature reaches the degree of 250 to 280, we will get the crude oil, the oil steam will be continuous produced until the temperature reaches 350-460°C; oil steam will flow through oil gas separator, light component will enter the condensers and meanwhile the heavy oil will be discharged automatically into in heavy oil tank. The liquefied part will be condensed as crude oil, and the part which cannot be liquefied will be transferred by the water seal back to the burning chamber to be reused as heating material.
End of Product from tire oil pyrolysis plant:
| NO. | Name | Percentage | Usage |
| 1 | Tyre oil | 40%~45% | * can be sold directly as fuel. * can be refine to diesel and gasoline by oil distillation plant |
| 2 | Carbon black | 37% | * can be sold directly. * can be refined by carbon black processing machine to make it finer (1500mesh finer). *can be made into pellet by pellet machine |
| 3 | Steel wire | 13% | *can be sold directly as steel or iron. |
| 4 | Waste gas | 5% | * can be recycled to heat up the reactor |
Oil recycling machine Installation: We will be in charge of arranging our engineer to go to your place to guide the installation and train your workers how to operate the 15 tons waste tire pyrolysis plant.
Oil recycle Land requirement: 300sq meters(10m*30m)
Tire oil machine Exporting Experience:
| America: | Brazil, Canada, Colombia, USA, |
| Middle East: | Dubai, Jordan, Saudi Arabia, Turkey |
| Europe: | Albania , Bosnia and Herzegovina |
| Asia: | Afghanistan, India, Malaysia, Pakistan, Philippines, South Korea, Vietnam, Myanmar,Thailand |
| Africa: | Ghana, Mozambique, Zambia |
