Reciprocating Piston Movement Z12V190b Diesel Engines and Parts for Wide Application
Price:
10-1000
MOQ:
1
Delivery Time:
15 days
Product Description
In-line diesel engines is a new-type diesel engine for the power supply of boat. It adopts advanced design idea and introduces advanced technology. Faeatured with good economic performance, small volumn, compact structure, great power, in-line diesel engine can oprated reliably.
JiNan GuoHua Green Power Equipment Co.Ltd, is professional production in diesel generator sets, gas generator sets and parts for nearly 12 years, covering production, sales and maintenance, having CE,ISO general notary certificate,etc. At present, we have formed a perfect sales and maintenance sreveice system. And have set up two workingroom, covering an area of more than 5,000 square meters. The company has strong technical force, excellent equipment. We would like to serve the customers around the world with our quality first products, reasonable price.
JiNan GuoHua Green Power Equipment Co.Ltd, is professional production in diesel generator sets, gas generator sets and parts for nearly 12 years, covering production, sales and maintenance, having CE,ISO general notary certificate,etc. At present, we have formed a perfect sales and maintenance sreveice system. And have set up two workingroom, covering an area of more than 5,000 square meters. The company has strong technical force, excellent equipment. We would like to serve the customers around the world with our quality first products, reasonable price.
Compression ratio of the gas generator is 14:1, No.and layout of clinders is 12-cylinder,60° Vee.
The main technical data is as follows:
| Type | Four stroke,water cooled, turbocharged and aftercooled,direct injection |
| Bore | 190 mm |
| Stroke | 210 mm |
| Direction of ratio | Counter-clockwise |
| Starting method | Air motor,electric motor |
If want to know more details, please contact us freely.
| Spare parts for 12V190 | |||
| No. | Part Name | Part Number | Qty |
| 1 | CYLINDER BLOCK ASSEMBLY | 1 | |
| 1 | |||
| 3 | CYLINDER HEAD ASSEMBLY | 127.03.00 | 12 |
| 4 | OIL SUMP ASSEMBLY | 12VB.04.00B | 1 |
| 5 | PISTON AND CONNECTING ROD ASSEMBLY | 127.05.00 | 12 |
| 6 | CAMSHAFT AND GEAR TRAIN ASSEMBLY | 127.06.00 | 1 |
| 7 | TORSIONAL VIBRATION DAMPER ASSEMBLY | 12VB.07.00 | 1 |
| 8 | INTAKE LINE ASSEMBLY | 127.08.00B | 1 |
| 9 | EXHAUST LINE ASSEMBLY | 127.09.00A | 1 |
| 11 | NATURAL GAS PIPELINE | 127.14.00 | 1 |
| 12 | MEGNETO TRANSMISSION ASSEMBLY | 127.15.00 | 1 |
| 13 | OIL PUMP ASSEMBLY | 12V.17.00C | 1 |
| 14 | OIL FILTER ASSEMBLY | 12VB.18.00B | 1 |
| 15 | CENTRIFUGAL FILTER ASSEMBLY | 12VB.19.00 | 1 |
| 16 | LUBRICATING PIPING | 127.20.00 | 1 |
| 17 | OIL COOLER ASSEMBLY | 12VB.21.00 | 1 |
| 18 | WATER PUMP ASSEMBLY | 12VB.22.00B | 2 |
| 19 | Cooling line system | 127.24.00 | 1 |
| 20 | INTER-COOLER ASSEMBLY | 12V.27.00 | 1 |
| 21 | HAND PRIMING OIL PUMP ASSEMBLY | 12V.29.00 | 1 |
| 25 | OVERSPEED SAFETY DEVICE | 12VB.37J2.00 | 1 |
| 26 | SPECIAL TOOLS | 127.42.00 | 3 |
| 27 | COUPLING ASSEMBLY | 163.44.00 | 1 |
| 29 | ELECTRIC STARTING SYSTEM | 127.46D.00 | 1 |
| 30 | OIL PUMP BRACKET ASSEMBLY | 12VB.48.00 | 1 |
| 31 | CARBURETTER ASSEMBLY | 127.86.00 | 2 |
| 32 | NATURAL GAS PRESSURE REGALATING VALVE | 127.87.00 | 1 |
| 33 | GOVERNOR CONNECTION ASSEMBLY | 127.89.00 | 1 |
| 35 | Electromagnetic valve | 127.91.00 | 1 |
| 36 | TURBOCHARGER ASSEMBLY | 127.20GJ.00EB | 2 |
