Samples US 1/Piece PVC Ball Valve DIN ANSI JIS BS Standard Anis Cns
High Quaility PVC Ball Valve for Industry
| Product name | PVC Ball Valve |
| Connection | Socket,Thread |
| Body material | PVC,UPVC,CPVC |
| MOQ | 1000pcs |
| Feature | UV Production |
| Color | Grey Body Red Handle |
| Material | Plastic |
| Standard | BSPT, NPT |
| Usage | Indusrial |
| Packing | Color Box |
| NO | BODY | Material | QTY |
| 01 | BODY | UPVC,CPVC | 1 |
| 02 | STEMO-RING | EPDM,FPM (NBR) | 1 |
| 03 | STEM | UPVC, CPVC | 1 |
| 04 | BALL | UPVC,CPVC | 1 |
| 05 | SEATSEAL | TPE,TPV,TPO | 2 |
| 06 | CAP | PVC,ABS | 1 |
| 07 | HANDLE | PVC,ABS | 1 |
| 08 | SCREW | SS304,STEEL | 1 |
Our PVC ball valve is 100% new material quality.So our products have good looking and are durable.
The colors of the valve body and handle can be customized.
Meanwhile, our handle of PVC valve is easy to operate,and We guarantee all the products are well manufactured in every process,from start to finish. Every piece is tested with no leakage before being delivered.
What's more, we are willing to offer free samples for testing!
| Model | DN | 15 | 20 | 25 | 32 | 40 | 50 | 65 | 80 | 100 | |
| SIZE | 1/2" | 3/4" | 1" | 1-1/4" | 1-1/2" | 2" | 2-1/2" | 3" | 4" | ||
| QX03 | thd./in | NPT | 14 | 14 | 11.5 | 11.5 | 11.5 | 11.5 | 8 | 8 | 8 |
| BSPT | 14 | 14 | 11 | 11 | 11 | 11 | 11 | 11 | 11 | ||
| JIS | l | 20 | 23 | 25 | 27 | 31 | 34 | 45 | 50 | 55 | |
| d1 | 22.3 | 26.3 | 32.33 | 38.43 | 48.46 | 60.56 | 76.6 | 89.6 | 114.7 | ||
| d2 | 21.7 | 25.7 | 31.67 | 37.57 | 47.54 | 59.44 | 75.87 | 88.83 | 113.98 | ||
| ANSI | l | 20 | 23 | 25 | 27 | 31 | 34 | 45 | 50 | 55 | |
| d1 | 21.54 | 26.87 | 33.65 | 42.42 | 48.56 | 60.63 | 73.38 | 89.31 | 114.76 | ||
| d2 | 21.23 | 26.57 | 33.27 | 42.04 | 48.11 | 60.17 | 72.85 | 88.7 | 114.07 | ||
| DIN | l | 20 | 23 | 25 | 27 | 31 | 34 | 45 | 50 | 55 | |
| d1 | 20.3 | 25.3 | 32.3 | 40.3 | 50.3 | 63.3 | 75.3 | 90.3 | 110.4 | ||
| d2 | 20 | 25 | 32 | 40 | 50 | 63 | 75 | 90 | 110 | ||
| d | 15 | 19 | 24 | 30 | 34 | 45 | 55 | 70 | 85 | ||
| H | 37 | 55 | 66 | 73 | 81 | 91 | 99 | 121 | 134 | ||
| A | 68 | 80 | 94 | 100 | 110 | 136 | 170 | 210 | 236 | ||
| L | 77 | 91 | 103 | 111 | 123 | 146 | 178 | 210 | 255 | ||
| D | 30 | 35.5 | 43 | 52 | 62 | 75 | 91 | 106 | 130 | ||
1.Low minimum order quantity
2.Can be customized,handle can be laser marked
3.Customer's design and logo are welcome.
4.Light weight, easy to handle and transport;
5.Better quality, higher value,well and high quality control, within 1% leakage;
6.Environment friendly, non-toxic, good looking and long service life;
7.Wonderful ability in chemical corrosion resistance;
8.Easy and fast installation, making cost minimized;
9.Soft colors and excellent design, suitable for installation either exposed or hidden;
FAQ:
1.Are you a manufacture or trading company?
We are a well-known supplier for plastic piping system in the world with 15 years professional experience. Welcome to visit and investigate us, you would find the difference with others.
2. Do you offer OEM service?
Yes. We have our famous brand name. But we can offer OEM service also,with same quality. We have customization services for packing,out-looking and logo.
3. Can you provide samples?
Yes.We provide samples for free and shipping fee is negotiable.
4. Why choose QX?
(1) We provide OEM service and submit Various styles, latest designs to our clients;
(2) We work with big customers in Southeast Asia, Africa, Middle east, North America, South America;
(3) According to the needs of customers in different regions, we match different quality and thickness valves with various styles, so that our customers are very competitive in the market!
(4)Our high quality PVC valve can be consistent with European and American national brand valves!
(5) We have great experience on providing high quality products and most professional service to clients about 10 years more!
(6). Customers choose our products, can mix and match our PVC pipe fittings, PVC butterfly valves, PP Fittings, irrigation products to buy together, so that the customer product line is more abundant, both quality and delivery time are guaranteed.
(7) We can flexible from China any port export ! Welcome you inquiry us!
