75HP Single stage Screw Type Permanent Magnetic VSD air compressor 55kw

Product introduction

Jufeng permanent magnet variable frequency screw air compressor delivers high efficiency, stable performance, and significant energy savings. Equipped with a permanent magnet motor and advanced frequency conversion technology, it adjusts speed automatically to match demand, reducing power consumption by up to 30%. Ideal for industrial use, it ensures low noise, minimal maintenance, and long service life.

Product Parameters

Model:                            JM-75A

Power:                           55kw

Exhaust volume:          10.5/9.6/8.5/8.1m³/min

Pressure:                       0.7/0.8/1.0/1.2Mpa

Noise level:                   74±2dB(A)

Outlet pipe diameter:   G2''

Dimension:                   1800*1250*1600mm

Weight:                          1180kg

Product photo:

The advantages of variable frequency air compressors

The first energy saving of inverter compressor

Variable flow,aviod the waste of loading and unloading control

Variable frequency compressor with its speed changing control technology which perfectly meet customer requirment.Not only reduces the high-loaded running current,but also avoids the waste if energy by 45%in unloading.

The second energy saving of inverter compressor

Maintain the pressure and supply the air,avoiding the waste of pressure gap by 2 bar Variable frequency compressor maintains the pressure at 6bar and supply the air constantly,not only ensure the stable air supply pressure but also avoids the high-load current waste caused by 2 bar pressure gap.
