China PC200-6 SWING REDUCTION 20Y-26-00150 20Y-26-00151 20Y2600150 20Y2600151 SWING MACHINERY ASSY PC200-6 SWING GEARBOX for excavator for sale

PC200-6 SWING REDUCTION 20Y-26-00150 20Y-26-00151 20Y2600150 20Y2600151 SWING MACHINERY ASSY PC200-6 SWING GEARBOX for excavator

Name: PC200-6 SWING REDUCTION 20Y-26-00150 20Y-26-00151 20Y2600150 20Y2600151 SWING MACHINERY ASSY PC200-6 SWING GEARBOX for excavator
Brand: Jiangmen Liba euipment Co., Ltd.

Price Negotiable

Price: Negotiable

MOQ: Negotiable

Delivery Time: Negotiable

Product Description

PRODUCT PARAMETERS

Part name	PC200-6 Swing gearbox
Equipment	Apply to KOMATSU EXCAVATOR
Part no.	20Y-26-00150 20Y-26-00151
NO.1 sun gear spline teeth	19 splines
Swing pinion shaft teeth	15 T
Item condition	New
Logo	LB
Gross weight	17 kg
MOQ	1 pc

Product Description

Parts on group :

Pos.	Part No	Qty	Parts name	Comments
	20Y-26-00151	[1]	SWING MACHINERY A. Komatsu	190 kg.
			["SN: 102083-UP"] analogs:["20Y2600150"] \|1.
	20Y-26-00150	[1]	SWING MACHINERY A. Komatsu	190 kg.
			["SN: 96514-102082"] analogs:["20Y2600151"] \|1.
1.	20Y-26-22210	[1]	CASE Komatsu	76 kg.
			["SN: 96514-UP"]
2.	20Y-26-22330	[1]	BEARING Komatsu China	3.28 kg.
			["SN: 96514-UP"] analogs:["20Y2622331", "20Y2622430"]
3.	20Y-26-22340	[1]	BEARING Komatsu China	9.6 kg.
			["SN: 96514-UP"] analogs:["20Y2622342", "20Y2622440"]
4.	20Y-26-22191	[1]	COVER Komatsu	4.6 kg.
			["SN: 97767-UP"] analogs:["20Y2622190"]
	20Y-26-22190	[1]	COVER Komatsu	4.6 kg.
			["SN: 96514-97766"] analogs:["20Y2622191"] \|4.
5.	01010-81045	[12]	BOLT Komatsu	0.039 kg.
			["SN: 96514-UP"] analogs:["0101051045", "01010D1045"]
6.	01643-31032	[12]	WASHER Komatsu	0.054 kg.
			["SN: 80001-UP"] analogs:["802150510", "0164331030", "0164381032", "0164371032", "0164331022", "0164321032", "0164301032", "6127212530", "802170002", "R0164331032"]
7.	20Y-26-22420	[1]	SEAL Komatsu China	0.3 kg.
			["SN: 97767-UP"]
	07012-00125	[1]	SEAL Komatsu China	0.142 kg.
			["SN: 80001-97766"] \|7.
		[-1]	.(20Y-26-22420{20Y-26-22191)}
			\|$$12.
8.	20Y-26-21141	[1]	SHAFT¤ 15 TEETH Komatsu OEM	35 kg.
			["SN: 96514-UP"] analogs:["20Y2621140", "20Y2621142"]
9.	20Y-26-22170	[1]	CARRIER Komatsu	8.55 kg.
			["SN: 96514-UP"]
10.	20Y-26-22141	[4]	GEAR¤ 36 TEETH Komatsu China	1.8 kg.
			["SN: 97709-UP"] analogs:["20Y2622140"]
	20Y-26-22140	[4]	GEAR¤ 36 TEETH Komatsu China	1.8 kg.
			["SN: 96514-97708"] analogs:["20Y2622141"] \|10.
11.	20G-26-11240	[4]	BEARING Komatsu China	0.24 kg.
			["SN: 96514-UP"] analogs:["20G2611241", "20G2611410"]
12.	20Y-27-21240	[8]	WASHER Komatsu China	0.02 kg.
			["SN: 96514-UP"]
13.	20Y-26-22250	[4]	PIN Komatsu China	0.52 kg.
			["SN: 96514-UP"]
14.	20Y-27-21280	[4]	PIN Komatsu China	0.01 kg.
			["SN: 96514-UP"]
15.	20Y-26-21240	[1]	PLATE Komatsu	5.1 kg.
			["SN: 80001-UP"]
16.	112-32-11211	[1]	BOLT¤ SHOE Komatsu	0.09 kg.
			["SN: 80001-UP"]
17.	20Y-26-22151	[1]	GEAR¤ 101 TEETH Komatsu	18.8 kg.
			["SN: 102083-UP"] analogs:["20Y2622150"]
	20Y-26-22150	[1]	GEAR¤ 101 TEETH Komatsu	18.8 kg.
			["SN: 96514-102082"] analogs:["20Y2622151"] \|17.
18.	20Y-26-22131	[1]	GEAR¤ 27 TEETH Komatsu	2.15 kg.
			["SN: 97709-UP"] analogs:["20Y2622130"]
	20Y-26-22130	[1]	GEAR¤ 27 TEETH Komatsu	2.15 kg.
			["SN: 96514-97708"] analogs:["20Y2622131"] \|18.
19.	04064-07525	[1]	RING Komatsu	0.026 kg.
			["SN: 96514-UP"]
20.	20Y-26-22220	[1]	THRUST WASHER Komatsu	0.04 kg.
			["SN: 96514-UP"]
21.	20Y-26-22160	[1]	CARRIER Komatsu	5.1 kg.
			["SN: 96514-UP"]
22.	20Y-26-22120	[3]	GEAR¤ 39 TEETH Komatsu China	1.25 kg.
			["SN: 96514-UP"]
23.	20Y-26-21281	[3]	BEARING Komatsu	0.1 kg.
			["SN: 110071-UP"] analogs:["20Y2621280", "20X2621240", "20Y2621510"]
	20Y-26-21280	[3]	BEARING Komatsu	0.1 kg.
			["SN: 80001-110070"] analogs:["20Y2621281", "20X2621240", "20Y2621510"] \|23.
25.	20Y-26-22240	[3]	PIN Komatsu	0.367 kg.
			["SN: 96514-UP"]
27.	20Y-26-22110	[1]	GEAR¤ 22 TEETH Komatsu	0.4 kg.
			["SN: 96514-UP"]
28.	20Y-26-22230	[1]	THRUST WASHER Komatsu	0.1 kg.
			["SN: 96514-UP"]
29.	20Y-26-22410	[1]	COVER Komatsu China
			["SN: 96514-UP"]
30.	01011-81450	[4]	BOLT Komatsu China
			["SN: 96514-UP"]
31.	01643-31445	[4]	WASHER Komatsu	0.019 kg.
			["SN: 96514-UP"] analogs:["0164301432"]
32.	07042-30617	[1]	PLUG Komatsu China
			["SN: 96514-UP"]
33.	07042-30108	[1]	PLUG Komatsu	0.008 kg.
			["SN: 96514-UP"] analogs:["0704220108"]
34.	07042-30415	[1]	PLUG Komatsu	0.056 kg.
			["SN: 96514-UP"]
