Medical Equipment Through Bore Slip Ring Capsule 12 Circuits 2A
Through-Bore Capsule Slip Ring 12 Circuits 2A
Product Description:
Features:
- Through-Hole Design: The slip ring features a through-hole design, allowing a central opening for passing shafts, cables, or other components through the slip ring assembly.
- 12 Circuits: It provides 12 independent circuits for the transmission of signals or power, offering versatility and flexibility for various applications.
- 2A Current Rating: With a 2A current rating per circuit, the slip ring can handle moderate current requirements, enabling reliable power transmission.
- Low Electrical Resistance: The slip ring is designed with low electrical resistance to minimize power loss and ensure efficient transmission of electrical signals.
Typical Application:
- Medical Equipment: RF slip rings are employed in medical devices and equipment, such as MRI machines and robotic surgery systems, for the transmission of RF signals essential for diagnostics and treatment.
- Industrial Automation: They are utilized in automated systems where RF signals are involved, such as robotic arms, assembly lines, and industrial control systems, ensuring seamless transmission and control of RF signals.
- Research and Development: RF slip rings are utilized in various research and development applications, including scientific experiments, prototype testing, and specialized equipment requiring RF signal transmission.
Specifications:
| Electrical Parameter | |
| Circuits &Current | 12 / 2A |
| Lead Wire Size | Φ0.8-AWG28# Teflon Insulated |
| Voltage | 0-24VAC/DC |
| Dielectric Strength | ≥500V@50Hz |
| Insulation Resistance | 300㏁@300VDC |
| Electrical Noise | ≤35㏁ |
| Mechanical Parameter | |
| Lead Wire Size | Stator:270±5mm Rotor:380±5mm |
| Working Speed | 0~300rpm |
| Contact Material | Gold-On-gold |
| Housing Materia | Engineering Plastics |
| Working Temperature |
-20'C~+80℃ |
| Working Humidity | ≤60%RH |
| Protection(IP Grade) | IP40 |
Drawing for HC24512-B01:
FAQ:
Can a Capsule Slip Ring transmit both power and signals?
Yes, a Capsule Slip Ring can transmit both power and signals simultaneously. It can accommodate a wide range of power requirements, from low voltage and current signals to high-power applications.
Can a Capsule Slip Rings transmit different types of signals?
Yes, a Capsule Slip Ring can transmit various types of signals, including analog, digital, video, audio, and data signals.
Is it possible to integrate multiple Capsule Slip Ringss in a system?
Yes, multiple Capsule Slip Rings can be integrated into a system by connecting and coordinating their electrical connections to meet the specific requirements of the application.
