Solar Lighting Trailer Mobile LED Light Trailer For Outdoor Job Sites Lighting
Solar Lighting Trailer Mobile LED Light Trailer For Outdoor Job Sites Lighting
The Model 3380 solar trailer is a solar lighting solution that combines green economy, intelligent efficiency, safety and robustness, flexibility, and long-lasting reliability. It is perfectly suited for off-grid locations, high-security requirements, and various mobile lighting applications.
Clean Energy
- Completely powered by solar energy, requiring no fuel or external power grid connection.
- No exhaust emissions, no noise, environmentally friendly, suitable for environmentally sensitive areas.
- The solar power system has a simple structure, long battery life, and requires minimal daily maintenance.
Easy to Operate
- Utilizing 3*380W monocrystalline silicon solar panels, it boasts high energy conversion efficiency and fast charging speed.
- Intelligent Deployment and Adjustment: Electric actuators allow for one-button deployment of the solar panels, with an adjustable angle of 0-65°, maximizing sunlight reception.
- Intelligent Control System: Supports multi-level dimming, timer control, and remote operation, improving energy efficiency and convenience.
Durable and robust
- 4*200AH batteries are housed in a sealed enclosure.
- The overall structure is waterproof and dustproof, resistant to high and low temperatures, and wind-resistant and stable, making it suitable for harsh outdoor conditions.
- It features multiple safety protection mechanisms, including overcharge, over-discharge, short circuit, and temperature protection.
Flexible and Portable
- The trailer-mounted design facilitates transportation and on-site mobility, allowing for quick deployment and immediate use.
- It covers a wide range of lighting needs for construction, emergency rescue, mining, agriculture, outdoor activities, road work, and more.
- Independent of infrastructure, it is particularly suitable for remote areas, emergency situations, and temporary operations.
|
Solar panels |
3*380W, monocrystalline silicon, solar angle adjuster 0-65 degree |
|
Battery |
4*200 AH DC12V 9600wh |
|
Mast |
7m electric |
|
LED |
4*100W, 360-degree lamp head rotation, 90-degree lamp head tilt device |
|
Controller |
MPPT 60A, 95% |
|
System voltage |
DC 48V |
|
LCD Control |
power consumption, charging status, loading status, PV voltage / current / wattage, error alert |
|
Running time |
20 to 24 hours |
|
Trailer |
R14 tires, 50mm ball/70mm ring,US standard, ball hitch, single axle, manual outrigger, 4 support legs, handbrake |
|
Weight |
about 1300kg |
|
Expandable size |
3400*3100*7000mm |
