Modern Design Style 1mm HDPE Geomembrane Liner Customized for Tunnel Lining Solutions
1mm HDPE Geomembrane Liner Geomembranas for Tunnel Liner
Geomembrane is made from high grade polyethylene raw material ,with carbon black ,antioxidant, anti-aging and UV resistance component.
Application industry or engineering & usage:
1. Environmental protection
2. Water conservancy
3. municipal engineering
4. garden
5. petrochemicals
6. mining
7. traffic facilities
8. agriculture
9. fish farm area
10. seepage,corrosion,leaks control & reinforcement for other facility,leachate collextion
11. temporary container structure,prefabrication of special parts.
| Property | Value | ||||||
| 0.75mm | 1.00mm | 1.25mm | 1.50mm | 2.00mm | 2.50mm | 3.00mm | |
| Density G/CM3 | 0.94 | ||||||
| Tensile properties |
|
|
|
|
|
|
|
| Strength at yield, N/mm | 11 | 15 | 18 | 22 | 29 | 37 | 44 |
| Break at yield, N/mm | 20 | 27 | 33 | 40 | 53 | 67 | 80 |
| Elongation at yield, % | 12 | ||||||
| Elongation at break, % | 700 | ||||||
| Right angle tear strength, N | 93 | 125 | 156 | 187 | 249 | 311 | 374 |
| Puncture strength, N | 240 | 320 | 400 | 480 | 640 | 800 | 960 |
| Stress crack resistance using notched constant tensile load, H | 300 | ||||||
| Carbon Black Content of a % | 2.0-3.0 | ||||||
| Standard OIT,MIN; | 100 | ||||||
| Pressure OIT,MIN | 400 | ||||||
