Strong Neodymium Countersunk Disc Magnets Countersunk Rare Earth Magnets
Strong Neodymium Disc Magnets Permanent Rare Earth Countersunk Hole Magnets
Product Parameter
| Manufacturer | Anhui Lulang New Material |
| Product Name | Magnetic Hooks/Strong Magnetic Hooks |
| Magnet Grade | N38-N52 |
| Surface Plating | Nickel Plating |
| Working Temperature | 80 Degrees Celsius |
| Packaging Method | White Box Packaging/Combination Bag Packaging/Bulk |
Product Specifications
| Model | D(mm) | D1(mm) | D2(mm) | H(mm) | Sink Hole Angle | Breakwuay(KG) |
| A16 | 16 | 3.5 | 6.5 | 5 | 90° | 5 |
| A20 | 20 | 4.5 | 8.6 | 7 | 90° | 6 |
| A25 | 25 | 5.5 | 10.5 | 7 | 90° | 14 |
| A32 | 32 | 5.5 | 10.5 | 7 | 90° | 25 |
| A36 | 36 | 6.5 | 12 | 7.6 | 90° | 29 |
| A42 | 42 | 6.5 | 12 | 8 | 90° | 37 |
| A48 | 48 | 8.5 | 16 | 11.5 | 90° | 68 |
| A60 | 60 | 8.5 | 16 | 15 | 90° | 112 |
| A75 | 75 | 10.5 | 19 | 18 | 90° | 162 |
Product Feature
1. Unique design: Strong disc neodymium magnet is made of NdFeb magnetic material. They can attract a variety of materials made from ferromagnetic elements, including nickel, iron, cobalt and their alloy parts. Powerful magnetism exists forever! Coated with three layers of nickel, copper and nickel to reduce corrosion and provide a smooth surface, greatly extending the life of the magnet.
2. Easy to use: Circular rare earth magnets can be directly adsorbed on magnetic materials, and can also be fixed on non-magnetic materials with screws. Strong and reliable. When separating the magnet, be careful and slide gently.
3. Wide range of uses: Circular magnets with holes can be widely used in daily life or work: tool storage, refrigerator magnets, jewelry, photos, greeting card display. They can also be used for science experiments, handicrafts and DIY projects.
4. Quality assurance: High quality neodymium disc magnets are inspected during and after production, and your purchase is protected. If you have a quality issue, please contact us and we will be happy to help you with a refund or replacement.
