HX20EPL Semi Auto Elastic Pen Loop Applying Machine suitable for applying elastic loops on cased in notebooks agendas and diary covers
HX20EPL Semi Auto Elastic Pen Loop Applying Machine
HX20EPL Semi Auto Elastic Pen Loop Applying Machine is a specialized machine designed to apply one elastic pen loop onto notebook, agenda, or diary cases or onto already cased-in products by hot-melt glue. Manual positioning of the flat covers or notebooks already cased in on the feeder, cutting off the elastic band directly from the roll, automatic positioning of the elastic band and threading of the same in the cuts previously done, automatic hot-melt gluing and pressing of the elastic, then delivery of the final product back to the operator to maintain the safety of the operation.
MBO Stahl Paper Folder Paper Folding Machine CP GUK trifold for sale operator second hand used new manufacturer made in china shoie horizon Heidelberg Komori buckle leaflet brochure bookbinding post press auto folder combi combination HXCP Aster sewing machine thread sewing machine muller martini program control book block Smyth Sewn Binding HXCP bible notebook hardcover book case maker case making machine case maker hardcover case rigid box gift box board cardboard case lining hot melt gluing cold glue white glue BDM UNIVERSAL HÖRAUF Kolbus photobook
| Model | HX20EPL |
| Cover Length Range | 100-300mm |
| Case Thickness Range | 1-3.5mm |
| Elastic Width Range | 6-30mm |
| Loop Diameter Range | 3-10mm |
| Capacity | 1000-1200pcs/h |
| Voltage | 220V, 50/60Hz |
| Power | 2.5Kw |
| Dimensions | 1500×860×1100mm(L×W×H) |
- Semi-Automatic Operation: The machine blends manual and automated processes. Manual positioning of the product is required, while cutting, positioning, gluing, and pressing of the elastic loop are automated.
- Hot-Melt Glue Application: The machine utilizes hot-melt glue to adhere the elastic pen loop to the product, suggesting a rapid bonding and potentially durable attachment.
- Integrated Elastic Band Processing: The machine handles the elastic band directly from a roll, cutting it to the required length automatically. It also includes automatic positioning and threading of the elastic into pre-made cuts on the product.
- Product Handling for Various Formats: The machine is designed to handle flat covers, notebooks, agendas, diaries, and already cased-in products, indicating versatility in product size and construction.
- Safety-Oriented Design: The machine emphasizes operator safety by requiring manual product loading and unloading, keeping the operator away from the primary automated processes.
