Automatic Pharmacy Tablet Press Machine 25mm Diameter Medicine Powder Press Machine
Pharmacy field medicine powder automatic tablet press machine 25mm diameter
ZP15/1719A automatic tablet press machine suitable for small batch production, lts feature is that 15-19 pairs of stamping dies can be installed on the rotary table, and 15-19 pieces can be pressed after one revolution. The rotary table speed, material filling depth and tablet thickness can be adjusted.
Tablet machine for sale in cheap price, it can compresses granular raw materials into various ordinary and shaped pieces, mainly used in tablet production in the pharmaceutical industry.
Tablet press equipment is also suitable for chemical, food, electronics, plastics, powder metallurgy and other industrial sectors.
Structural Features of Pharmacy field medicine powder automatic tablet press machine 25mm diameter
1. GMP-compliant design;
2. High quality stainless steel construction;
3. Overall tight sealing and dust-proof design;
4. High-definition, isolated window design for easy disassembly, maintainability.
Technical of Pharmacy field medicine powder automatic tablet press machine 25mm diameter
|
Product Model
|
ZP15A
|
ZP17A
|
ZP19A
|
|
No. of punch die (set)
|
15
|
17
|
19
|
|
Max. Production Capacity (pcs/h)
|
31500
|
35700
|
40000
|
|
Max. Dia. of Tablet (mm)
|
3-25
|
3-20
|
3-13
|
|
Max. Thickness of Tablet (mm)
|
0-6
|
0-6
|
0-6
|
|
Max. Depth of Filling (mm)
|
15
|
15
|
15
|
|
Max. Pressure (kn)
|
80
|
60
|
60
|
|
Voltage
|
220/380
|
220/380
|
220/380
|
|
Power (kw)
|
3.0
|
2.2
|
2.2
|
|
Dimension (mm)
|
800*700*1750
|
||
|
Weight (kg)
|
500
|
500
|
500
|
Real Photos of Pharmacy field medicine powder automatic tablet press machine 25mm diameter
Pharmacy field medicine powder automatic tablet press machine 25mm diameter Details Show:
1. The whole machine is made of 304 stainless steel
Meet GMP requirements
Simple and convenient operation
2. Large diameter bucket for convenient storage
Transparent frame on the side of the barrel, material storage can be seen
3. Customized 15-19 punch according to customer needs
Rotate one cirde to press 15-19 pieces
4. Control switch button, control the speed of rotary table
5. Extension of the connecting plate in the outgoing area, more convenient connection
6. Two adjustment knobs on the side of the machine,
Pressure control valve
Powder amount adjusting knob
7. The machine is equipped with a vacuum cleaner interface, easy to link vacuum cleaner
8. The motor is placed in the cabinet, safer and cleaner
Application of Pharmacy field medicine powder automatic tablet press machine 25mm diameter
The rotary tablet machine slideshare is suitable for pressing:
1. Pharmaceutical: Chinese medicine tablets, western medicine tablets, nutrient tablets, pills
2. Food: candy tablets, coffee tablets, chocolate beans, seasonings, glucose tablets
3. Health care products: calcium tablets, buccal tablets, bee film, spirulina tablets, effervescent tablets
4. Agriculture: feed blocks, fertilizer tablets, animal food
5. Electronic battery: thermistor, integrated circuit components, button battery
6. Chemical: catalyst, disinfection tablets, mosquito repellent tablets, camphor balls, powder cakes, color particles
7. Metallurgical ceramic plastics: catalytic particles, glass powder particles, ceramic powder particles, metallurgical powder particles, plastic particles
Pharmacy Process of Pharmacy field medicine powder automatic tablet press machine 25mm diameter
