Wear Resistant Alumina Ceramic Tube 95% Ceramic Lined Composite Drainage Pipe

Price Negotiable

Price: Negotiation

MOQ: 2 piece

Delivery Time: To be negotiated

Brand: LJ Ceramic

Product Description

Alumina Ceramic Wear-Resistant Pipe Drainage Pipe Ceramic Lined Composite Pipe

The hardness of wear-resistant ceramics is higher, second only to diamond, far exceeding the wear-resistant steel and stainless steel wear resistance, also known as special corundum ceramics. It has stable chemical properties, in high temperature environment, will not occur deformation or damage, so it also has high temperature resistance.

Alumina Ceramic Properties

1. High voltage resistance

2. Excellent insulation performance

3. High corrosion resistance

4. High mechanical strength and hardness

5. Extremly abrasion resistance performance

6. High temperature up to 1600ºC

7. Wide scope of application

Alumina Ceramic Properties

Alumina Ceramic Properties		95%Al2O3	99%Al2O3	99.5%Al2O3
Item	Unit	Typical Values
Physical Properties
Color		White	Ivory	yellow
Density	g/cm3	>3.6	3.89	3.96
Alumina Content	%	95%	99%	99.50%
Gas permeability		0	0	0
Water Absorption		0	0	0
Mechanical Properties
MONS' Hardness	Grade	9	9	9
Rockwell Hardness	HRA	≥85	≥89	≥89
Vickers Hardness (Hv50)	Gpa(Kg/mm²)	15.7(1600)	15.7(1600)	15.7(1600)
Flexural Strength(20°C)	psiX103	358	550	550
Compressive Strength(20°C)	psiX103	2068(300)	2600(377)	2600(377)
Modulus of Elasticity	Gpa	275
Fracture Toughness(20°C)	Mpa.m3/2	4.3	5.6	6
Thermal Properties
Thermal Conductivity(20°C)	W(m.K)	16	30	30.4
Thermal Expansion(25-1000°C)	1X10-6/℃	7.6	7.9	8.2
Maximum Use Temperature	°C	1450	1600	1650
Thermal shock resistance	°C	250	200	200
Electronic Properties
Volume resistivity(100°C)	Ohm/cm2	>1013	>1014	>1014
Dielectric breakdown strength	KV/mm	8.7(220)	8.7(220)	8.7(220)
Dielectric Constant	Er	9	9.7	9.7
Dielectric constant (100MHz)	Er	9.5
