China best price siemens Profibus cable power cable

Application

Connecting cable for stationary installation in dry environments at the process level. Screening ensures reliable use in EMI environments. (Special characteristics: reduced fire propagation,low smoke emission,low fire load,no corrosive gas).

Standards

IEC 60332-3,IEC 60754-1,IEC 60754-2

Construction

Conductor:Bare Cu conductor

Insulation:Expanded PE,halogen-free

Insulation color:Red and green

Core twisted in layers,with optimal lay lengths

Screening:Overall screening with composite Al foil,metal layer on the outside,and tinned Cu braided screening

Outer sheath:Halogen-free compound,FRNC, flame retardant

Marking:Manufacture name (trademark) and type, Production year/week or batch number ,Metre-marked.

Technical

Temperature range - 25° C to + 60°C

Peak operating voltage:max.100V

Test voltage:3600V/3sec

Conductor loop resistance:max.110 Ohm/km

Insulation resistance:≥16000MOhm x km

Mutual capacitance at 1 kHz:approx 28.0 nF/km

Wave impedance:

Nominal value: 150 Ohm,3 to 20 MHz:150 +/- 15 Ohm,38.4 kHz:185 +/- 18.5 Ohm,9.6 kHz:270 +/- 27 Ohm

Attenuation:at 16 MHz: <42 dB/km,at 4 MHz:<22 dB/km,at 38.4 kHz:<4 dB/km,at 9.6 kHz:<2.5 dB/km

Bending radius:min.150mm

Flame retardant:To IEC 60332-1

Halogen-free:To IEC 60754-1

Corrosiveness of combustion gas:To IEC 60754-2

Please do not hesitate to contact us if you need the product detail or special product

Siemens Profibus  NET and S7 S5 PLC Programming cable

we can supply major SIEMENS A&D products including Siemens

Profibus  NET and cable S7 S5  PLC

Profibus NET
1 Profibus Bus cable,Purple PVC jacket, unshielded twisted pair 6XV1 830-0EH10

2 Profibus Bus connector ,900 angle round, non-programming port 6ES7 972-0BA12

3 Profibus Bus connector ,900 angle round, with programming port 6ES7 972-0BB12

4 Profibus Bus connector ,350 angle round, non-programming port 6ES7 972-0BA41

5 Profibus Bus connector ,350 angle round, with programming port 6ES7 972-0BB41

6 Profibus Bus connector ,Fast Terminal Blocks,900 angle round, non-programming port 6ES7 972-0BA51

7 Profibus Bus connector ,Fast Terminal Blocks, 900 angle round, with programming port 6ES7 972-0BB51

8 Isolated terminal, 900 angle round, non-programming port

9 BC 293, CPU 22X battery box 6ES7 291-8BA20

10 Plus memory card (a capacity of 64K) 6ES7 291-8GF23

11 20 pin linker (S7-300)6ES7 392-1AJ00-0AA0

12 40 pin linker (S7-300) 6ES7 392-1AM00-0AA0

13 S7-300 Installation guide(160 mm) 6ES7 390-1AB60-0AA0

14 S7-300 Installation guide(482 mm)6ES7 390-1AE80-0AA0

15 S7-300 Installation guide(530 mm)6ES7 390-1AF30-0AA0

16 S7-300 Installation guide(830 mm) 6ES7 390-1AJ30-0AA0

17 S7-300 Installation guide(2000 mm)6ES7 390-1BC30-0AA
