Most Popular Power Cable TC90 Aluminum Alloy Power Cable 70 mm2

Aluminum Alloy Cable Type

Aluminum Alloy Cable Description

YJLHV(TC90)

aluminum alloy conductor,XLPE insulated and PVC sheathed aluminum alloy cable

YJLHV₂₂(ACWU90)

aluminum alloy conductor,XLPE insulated ,steel tape armored and PVC sheathed aluminum alloy cable

YJLH₈(AC90)

aluminum alloy conductor,XLPE insulated,aluminum alloy tape self-locking armored aluminum alloy cable

YJLHV₈(AC90)

aluminum alloy conductor,XLPE insulated,PVC inner sheathed aluminum alloy tape self-locking armored aluminum alloy cable

YJLHV₈₂ (ACWU90)

aluminum alloy conductor,XLPE insulated, aluminum alloy tape self-locking armored PVC sheathed aluminum alloy cable

Application

This cable is suitable for power transmission and distribution line with voltage rated at 35kV and below.
For indoor and outdoor use. It can be buried direct or in underground ducts,in conduits. can be installed

vertically.

Installation conditions

1.Rated voltage: 0.6/1KV-26/35KV
2.The installation temperature should be above 0ºC

Structure

Conductor: Aluminum Alloy
Insulation: The cross-linked polyethylene (XLPE)
Amour: Interlocked Aluminum Tape Armored
Outer sheath: Polyvinyl chloride (PVC). Black colour

Features

1.Conductor: aluminum alloy,creep resistance,high flexibility,strong extension,
Low rebound and stable connection.
2.Insulation:High temperature resistant, anti combustion, anti-aging, durable and low carbon environmental protection.
3.Armored layer: Special form of self-locking, strong toughness.
4.Price: Same electrical properties,the price of Aluminum alloy cable is 15% --30%  lower  than traditional copper cable.
5.Weight:Under the same cross-section, the weight of aluminum alloy conductor cable is 50% of copper conductor cable
