NO! The casting on Clamping increases the grasping force, meanwhile does not scratch the material.
Ejon T20 Outdoor Advertising Neon Sign Making CNC Bend Letter Sign Bending Machine
Price:
$11,000.00/sets 1-2 sets
MOQ:
Negotiable
Delivery Time:
Negotiable
Brand:
EJON
Product Description
Product Description
EJON T20 shop sign makers stainless steel aluminum 3d letters sign bending machine channel letter bending machine for luminous advertising letters
dobladora de letras 3d, бортогибочный станок для букв, ماكينة الانحناء للحروف, maquina para hacer los letreros de led neon
Multifunction channel letter bending machine, Using mechanical hand alternately feeding structure, the stability of the feeding process is effectively guaranteed. Double ball screw with nylon gear, the feeding speed of the machine is greatly improved. The material clamp is made of structural castings, avoid scratching to the material while improving the feeding holding power.
SPECIFICATIONS | ||||||
Feeding system | Double ball-screw alternate feeding system | |||||
Slotting System | Plane cutter/Milling wheel cutter | |||||
Bending System | Double blade alternate bending system | |||||
Suitable Material | Stainless steel, Galvanized steel, Aluminum plate, Aluminum profile | |||||
Slotting trip | Plane cutter: 10~200 mm; Milling wheel cutter: 10~170 mm | |||||
Material Thickness | 0.4~1.2mm | |||||
Accuracy | ±0.1mm | |||||
Min. Bending Angle | R6 | |||||
File Format | Dxf.Plt.Ai | |||||
Power | AC220V、50Hz、2.0Kw | |||||
Air Supply | 0.6m3/min | |||||
Control System | 4 axis control system (4 axis servo control) | |||||
Letter Sample Show
Seiko letter
Resin letter
Narrow edge letter
Rimless letter
Luminous letter
Narrow edge letter
Detailed Images
* Scratch the metal surface?
* Is the feeding unstable?
NO! The double ball screw of feeding design ensure the feeding speed and precision as well as stability.
* Usually need to change the cutter?
NO! High strength alloy cutters are used for slotting knifes, each knife has 8 angles, no need to sharpen, meanwhile the slotting mechanism adds a new air blowing and
cooling function to extend the service life of the cutter while ensuring smooth slotting.* How about the precision?
The encoder module is the key component of the the relation equipment precision, and the precision casting is used to ensure the performance of the high precision encoder.750 W high-power servo motor also improves the positioning accuracy and the stability of high-speed bending.
Supporting Facility
Computer
To use the device, you need to install the control card in your computer and then connect to the bending machine and install the software.Computer configuration : XP system or window7 32-bit system, and requires a PCI card slot to install the control card.
Pump
The use of equipment should be equipped with air compressor, we suggest that the selection of more than 4kw, the gas flow is 0.6m³/Min.
File Format
The software of bending machine is self-developed. Import file format supports .Dxf.Plt .AI We recommend using Coredraw or adobe illustrator to complete the file after the export file to.Dxf.Plt.Ai format. Then open the operating software, select the document.
Our Service
Pre-Sales Service
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
After-Sales Service
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
Anything you want to know, we are always at your service, CLICK HERE TO CHAT!
Customer Photos
Kenya
Dubai
Vietnam
Thailand
Ukraine
USA
Customers' Feedback
Packing & Delivery
Packaging | ||
Size | 1330(L) * 740 (W) * 1500(D) | |
Weight | 350 | |
Packaging Details | The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request. | |
Packaging | ||
Size | 1330(L) * 740 (W) * 1500(D) | |
Weight | 350KG | |
Packaging Details | The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request. | |
