Stainless Steel 316 Wire Rope Netting Mesh 32mm Buckle Type Fencing
| Attribute | Value |
|---|---|
| Product Name | Rope Mesh Fencing |
| Wire Diameter | 1.2mm |
| Material | Stainless Steel 304, 316 |
| Color | Bright Silver |
| Mesh Size | 32mm |
| Length | 20m |
| Width | 8m |
| Type | Buckle Type |
| Sample | Free |
Our stainless steel wire rope mesh is manufactured from high-quality 304, 304L, 316, or 316L stainless steel, available in hand-woven, closed mouth, and open buckle configurations. Each mesh is assembled with 100% seamless rope ferrules for maximum durability and features optimal stretch at a 60° angle for easy installation with our special border design.
Available wire diameters: 1.0-4.0mm (customizable options include 1.2mm, 1.5mm, 2.0mm, 2.5mm, 3.2mm, and 4mm)
Available mesh sizes: 20-300mm
| Type | C (%) | Si (%) | Mn (%) | Cr (%) | Ni (%) | S (%) | P (%) |
|---|---|---|---|---|---|---|---|
| 304 | ≤ 0.07 | ≤ 1.0 | ≤ 2.0 | 17.0-19.0 | 8.0-11.0 | ≤ 0.03 | ≤ 0.035 |
| 304L | ≤ 0.03 | ≤ 1.0 | ≤ 2.0 | 17.0-19.0 | 8.0-12.0 | ≤ 0.03 | ≤ 0.035 |
| 316 | ≤ 0.08 | ≤ 1.0 | ≤ 2.0 | 16.0-18.5 | 10.0-14.0 | ≤ 0.03 | ≤ 0.035 |
| 316L | ≤ 0.03 | ≤ 1.0 | ≤ 2.0 | 16.0-18.0 | 12.0-15.0 | ≤ 0.03 | ≤ 0.045 |
- Steel Mesh Balustrade - bridge, stair, balcony, path
- Cable Mesh - Excellent Solution to Safety
- Safety Net - Structural Measure to Prevent Suicide
- Helipad Safety Net - Modular Heliport Webbing
- Cable Zoo Mesh - Solution to Enclosing Most Animals
- Aviary Netting - Lightweight, Durable and Long Lasting
- Green Facade - Cable System for Most Climbing Plants
Closed-type buckle: Features multiple steel wire ropes combined together for enhanced strength, though with multiple joints at the closure end.
Open-type buckle: Constructed from a single continuous steel wire rope for easier installation and a more aesthetically pleasing overall appearance.
