8 Channel 1080P AHD HD Hard Disk Storage Vehicle 3G Special Function Mobile DVR Camera
Richmor Factory Direct Sell 8 Channel 1080P AHD HD Hard Disk Storage Vehicle Mobile DVR 3G 4G GPS Wifi optional
| PRODUCT DESCRIPTION | |
| Resolution | 8X 1080P AHD Full real-time recording |
| Moduel | G-Sensor built in, GPS /3G/4G /WIFI Optional |
| Storage | Support 1X2TB Hard disk+ 1X128 GB SD card |
| Alarm I/O | 8CH Alarm input, 2CH Alram output |
| ACC Delay | 10 seconds delay pow-off for data protection |
| Voltage | 6V-36V Wide range voltage power supply |
Detailed specification was listed as follows for checking, please contact us we'll do our best to cooperate.
|
Item |
Parameter |
|||
|
OS |
Linux |
|||
|
Language |
Chinese/English/Others(can be customized) |
|||
|
Video Compression |
H.264 |
|||
|
OSD |
Overlays information such as date time and vehicle ID |
|||
|
Video Record System |
Video Input |
Support 8 CH Full real-time AHD 1080P |
||
|
Video Output |
2CH CVBS+ VGA output for optional, 1.0Vp-p, 75Ω |
|||
|
Preview |
Support 1 channel and 4 channels preview.,Support Manual/Alarm Trigger full screen preview |
|||
|
Video Quality |
0-7 levels, 0 is the highest level, 7 is the lowest level. |
|||
|
Resolution |
Support 4CH Full real-time AHD 1080P |
|||
|
Record Mode |
The default setting is auto recording after power on. Timed recording, alarm trigger recording and manual recording are supported. |
|||
|
Audio |
Audio Input |
4CH |
||
|
Audio Output |
2CH |
|||
|
Compression |
G.726 |
|||
|
Alarm |
Input |
8CH |
||
|
Output |
2CH |
|||
|
Storage |
Up to 2TB HDD & 128GB SD Card |
|||
|
Communication Port |
3CH RS232 / 2CH RS485 |
|||
|
G-sensor |
Built in, support 3 Axis Motion Detection with user set ranges , for X,Y and Z coordinates |
|||
|
Wireless communications |
GPS /3G /4G /WIFI optional |
|||
|
GPS |
Support Built GPS/BD Module,can support the ministry of communications |
|||
|
Video Playback |
Video Search |
Search video by Record Time/Type etc |
||
|
Playback |
Max support 8CH Replay /Stop/Fast Forward/Fast Reverse at same time |
|||
|
CMS |
Wireless(require Wi-Fi or cellular), real-time monitoring .GPS and alarm etc |
|||
|
Operating Voltage |
Voltage Input |
8V ~ 36V DC |
||
|
Voltage Output |
12V 2.5A |
5V 2.5A |
||
|
Power -off Protection |
All video information can be saved automatically when the power cut off, and make sure that all the files can not be damaged |
|||
|
Power Consumption |
Normal Working <10W |
|||
|
Other |
Operation Temperature |
-20℃ ~ + 70℃ |
||
|
Humidity |
20% ~ 80% |
|||
|
Dimension |
200*187*62mm |
|||
|
Weight |
1.9KG |
|||
| RCM-MDR7104 | ||
| a. Remote controller*1 | b. 6PIN power cable*1 | c. 16PIN output*1 |
| d. 24PIN alarm cable*1 | e. VGA switching cable(6 pin)*1 | f. USB cable*1 |
| g. 4G antenna |
h. GPS antenna |
i. WIFI antenna |
|
Shenzhen Richmor Technology Development CO.,LTD [ 100% OEM Manufacturer, Quality Assured, Price Competitive] |
|
|
Contact: Ada Lin Mob: + 86 18938073583 Skype: + 86 18938073583 Website: http://www.mdvrchina.com Company Add: 5th Floor, D Building, Bantian International Center, Bantian, Longgang District, Shenzhen, China. |
|
