Customized Box-type Diffusion Cyclone Dust Collector for Building Materials Casting
Price:
$2,300.00/sets 1-4 sets
MOQ:
1
Delivery Time:
Negotiable
Brand:
YITE
Product Description
The cyclone dust collector is a dry filter dust collector. When the dust is drawn into the cyclone dust collector by the
centrifugal fan, it will rotate from top to bottom along the wall. Therefore, the dust particles are separated from the airflow by the centrifugal force, and then fall into the ash hopper along the wall by gravity, and the gas will be discharged from the
discharge pipe upwards along the discharge pipe.
centrifugal fan, it will rotate from top to bottom along the wall. Therefore, the dust particles are separated from the airflow by the centrifugal force, and then fall into the ash hopper along the wall by gravity, and the gas will be discharged from the
discharge pipe upwards along the discharge pipe.
particlesabove 5μm, and the parallel multi-tube cyclone deduster device also has the dust removal efficiency of 80-85% for
particles at3μm.
Our Advantages
1.The equipment has small volume, simple structure, small floor space, low cost, small equipment resistance and large air volume;
2.No rotating mechanism and moving parts, convenient maintenance and management, no technical requirements;
3. can be used for the purification of high-temperature dusty gas
4.Dry dust removal is beneficial to the recovery of valuable dust;
5.Wide range of applications. Wear-resistant and corrosion-resistant linings are installed in the dust collector, which can be used to purify the flue gas containing highly corrosive dust.
2.No rotating mechanism and moving parts, convenient maintenance and management, no technical requirements;
3. can be used for the purification of high-temperature dusty gas
4.Dry dust removal is beneficial to the recovery of valuable dust;
5.Wide range of applications. Wear-resistant and corrosion-resistant linings are installed in the dust collector, which can be used to purify the flue gas containing highly corrosive dust.
diameter (mm) | Air volume(m³/h) | highly(mm) | Air inlet no flange | outlet no flange | weight (kg) | thickness (mm) | |||||
normal | max | With stents | no stents | ||||||||
YTXF-280 | 280 | 600 | 1000 | 800 | -200 | φ108 | φ140 | 15 | 2 | ||
YTXF-400 | 400 | 1300 | 2000 | 1600 | -400 | φ160-200 | φ200 | 45 | 2 | ||
YTXF-500 | 500 | 2000 | 3200 | 2000 | φ200-250 | φ250 | 65 | 2 | |||
YTXF-600 | 600 | 3200 | 4600 | 2400 | -800 | φ250-300 | φ300 | 95 | 2 | ||
YTXF-800 | 800 | 4600 | 8200 | 3200 | φ300-400 | φ400 | 190 | 2.5 | |||
YTXF-1000 | 1000 | 8200 | 12000 | 4000 | φ400-500 | φ500 | 310 | 2.5 | |||
YTXF-1200 | 1200 | 12000 | 18000 | 4800 | φ500-600 | φ600 | 430 | 2.5 | |||
YTXF-1300 | 1300 | 18000 | 21000 | 5200 | φ600-650 | φ650 | 520 | 2.5 | |||
FAQ
Q1.Are you a factory and trading company?
A: We are a factory
Q2. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.
Q3. Can you suggst me a suitable type?
A: Certainly, Once you give me the keyword. The most suitable size will be choose to meet your need
Q4. How about your delivery time?
A: Generally, it will take 7-30 days after receiving your advance payment. The specific delivery time depends on the items ,
transportation ways and the quantity of your order.
Q5. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.
Q6. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery
Q7: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they comefrom.
A: We are a factory
Q2. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.
Q3. Can you suggst me a suitable type?
A: Certainly, Once you give me the keyword. The most suitable size will be choose to meet your need
Q4. How about your delivery time?
A: Generally, it will take 7-30 days after receiving your advance payment. The specific delivery time depends on the items ,
transportation ways and the quantity of your order.
Q5. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.
Q6. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery
Q7: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they comefrom.
