70" Indoor Digital Advertising Screens Replacement Screen For LCD Advertising TV
Features (Wall-mounted LCD digital signage ):
1. High-resolution displays: 3840x2160, ensuring that content is clear and easily readable from a distance.
2. Remote Content Management, Digital signage systems come with free software that allows users to remotely update and manage content.
3. Scheduled Content Playback: Users can schedule content to play at specific times or dates, allowing for targeted messaging and advertising based on time of day or events.
4. Interactive touch screen optional,allowing users to manage directly with the content being displayed.
5. Support Customizable design, software
6. Remote Monitoring and Diagnostics: Some systems offer remote monitoring and diagnostics, allowing users to monitor the health of their signage displays and receive alerts if any issues arise.
8. Multi-Zone Layouts: Digital signage displays support to divided into multiple zones, allowing users to display different types of content simultaneously, such as advertisements, news updates, and event schedules.
Application:
Wll-mounted LCD digital signage offers a versatile and dynamic solution for displaying information and advertising in various indoor environments, including retail stores, restaurants, corporate offices, transportation hubs, and more.
Technical Parameters:
| PANEL PARAMETER | ||
| Prodcut name | 70" wall mounted lcd advertising player | |
| Panel type | TFT LCD screen, Led back light | |
| Resolution(Default) | 3840*2160 16:9 | |
| Brightness | 500cd/m2 | |
| Display area(H/V) | 1549.44 x 871.56mm | |
| Dot pitch(H/V) | 0.269x0.807 mm | |
| Contrast ratio | 4000:1 | |
| Display color | 16:7M(8bit) | |
| View angle(H/V) | 178/178 | |
| Response time | 6ms | |
| Tempered glass | 3.0mm (For protectiving LCD) | |
| Touch Sensor | Non touch/IR touch screen 10 points | |
| Operation System | ||
| USB or SD card | USB or SD card | 8G |
| Support | USB/SD card, input, Update contect by USD or SD card | |
| Android OS 7.0 to 11 | CPU | Quad-core 1.8GHz |
| Memory | DDR3 2G to 8G | |
| Built-in Storage | 8G to 32G FLASH/EMMD | |
| Network support | WIFI/RJ45/Bluetooth (4G/5G option) | |
| Port support | LAN/TF/USB/ output | |
| Windows OS 7/8/10 | CPU | I3/I5/I7 |
| Memory | 4G RAM, 128G SSD(up to 8-16G, 256G SSD) | |
| Network support | WIFI/RJ45/Bluetooth (4G option) | |
| Port support | LAN/USB/VGA and output/DC-IN, LIN-OUT, MIC-IN | |
| Support format | Video | MPGE1, MPGE2, MPEG4, ASP, WMV, AVI, H2.63, H.264, VC1, RV, etc. |
| Image | JPEG, BMP, TIFF, PNG, GIF | |
| Document | TXT, Word, PPT, Excel | |
| Audio | Wave, MP3, WMA, AAC | |
| Image resolution | Support 2160, 1080p, 720p, 480p, and multiple resolutions | |
| Technical Specification | ||
| Frame's material | Cold-Roll Steel Sheets(SPCC) | |
| Color | Black | |
| Menu Language | Multiple language, English(Default) | |
| Colored System | PAL/NTSC/Auto-detecting | |
| Speakers | 2x5W | |
| Noise Reduction | Yes | |
| Voltage Frequency | 100V-240V AC, 50/60Hz | |
| Power Consume(Max) | ≤190W | |
| Working Temperature | 0°C~50°C | |
| Working Humidity | 10% - 90% | |
| Storage Temperature | -20°C - 60°C | |
| Storage Humidity | 10%-95% | |
Support and Services:
Our Digital signage lcd product comes with comprehensive technical support and services to ensure your satisfaction:
- Phone and email support for any technical.
- Product installation and setup assistance
- Regular firmware updates to ensure optimal performance and compatibility
- Remote troubleshooting and diagnostic services
- Extended warranty options for added peace of mind
FAQ:
Q: What kind of inspection you can provide?
A: Zhongxin has multiple tests from material purchasing to finished products by different departments, like QA, QC, sales
representative, to guarantee all signage players are in perfect condition before shipment. We also accept the inspection by the third party you appointed.
Q: What is your guarantee period?
A: Zhongxin provides 1 (one) year quality guarantee for the products from your purchase date, except the human damage and force majeure factor. For a better maintenance, be sure that the players are using under normal circumstances (not more than 16 hours daily).
Beyond the guarantee period machine, Zhongxin will provide maintenance service and technical support (Hardware and other possible charges, we will not bear the responsibility)
Q: How can I pay for the order?
A: Our payment terms: T/T, Western Union, Paypal.
1) For sample order: 100% T/T or Western Union in advance, Paypal is also acceptable.
2) For bulk order: T/T (Bank Transfer), 30% down payment, 70% balance should be paid before the delivery of the goods.
