IP65 Safety Curtain Outdoor 30M Range For Large Industrial Door Anti Smashing

Name: IP65 Safety Curtain Outdoor 30M Range For Large Industrial Door Anti Smashing
Brand: Shenzhen Jutai Comm Co., Ltd.

Price Negotiable

Price: Negotiation

MOQ: 1

Delivery Time: 5 - 8 working days

Brand: JUTAI

Product Description

Safety Light Curtain Anti Pinch Photocell 1m 4 Beams for Industrial PVC Fast Door

Safety Light Curtain Sensor Product Description

Introduction:
The Safety Light Curtain Sensor offered by JUTAI that employs advanced infrared beam technology. It is designed to provide reliable object detection and trigger appropriate actions in a variety of settings.

Functionality:

For Industrial Doors: If an object is detected while the door is closing, it automatically reopens to prevent potential accidents and safeguard both people and equipment.
In Barrier Gate Applications: Ideal for barrier gates, it quickly reopens if a person or vehicle is detected during closure, enhancing safety at access points.
For Home Security: When it detects unauthorized entry, it activates a relay output, serving as an effective deterrent against intruders and enhancing home security.

Key Features and Advantages:

Exceptional Durability: Engineered to withstand significant light interference and harsh outdoor conditions. With an IP65 waterproof rating, it offers remarkable resilience and long-term performance.
Extensive Detection Range: Boasts a detection range of over 15 meters, providing broad coverage for large areas.
Customization Options Galore: Can be tailored in various lengths and beam configurations to meet specific requirements, ensuring flexibility for different applications.
Rapid Response Time: Features adjustable response times of 50/100/150/200ms, enabling quick detection and response to objects.
Selectable Trigger Modes: Offers the choice between single beam trigger and multi-beam trigger, allowing for customization based on specific safety needs.
180-Degree Horizontal Rotation: Allows for flexible installation and optimal detection in different orientations.

Applications:

Industrial doors and barrier gates to enhance safety during operation.
Home security systems to detect unauthorized entry and trigger alarms.

Specification Table:

Specification	Details
Model	PB20-16L15
Technology	Infrared Optical Technique
Detection Mode	Presence detect
Number of Beams	4 (Customizable)
Length	1m (Customizable)
Detection Distance	15m
Operating Voltage	12 - 24V
Transmitter Operating Current	<50mA
Receiver Operation Current	<50mA
Response Time	50/100/150/200ms adjustable
Trigger Time	Blocks a beam of light and triggers in 2 seconds; blocking adjacent 2 beams or more triggers immediately
Trigger Method	Single beam trigger or Multi-beam trigger (selectable)
Working Temperature	-20~60℃
Relative Humidity	Up to 90%RH (non-condensing)
Alarm Output	Wired Output, relay Output 30VDC@2A, 125VAC@1A
Output Way (Wired Model)	Wired transmission (NO/NC)
Rotation Angle	180 degrees horizontal
IP Level	IP65
Material	Aluminum Alloy and PC Plastic

Wiring Definition

Size

Installation

How to install JUTAI Infrared Curtain Photocell? We have also listed the installation drawings step by step for customers' reference, making the installation simple, easy and fast;

Safety Light Curtain Sensor Installation Guide and FAQs

Installation Steps:

1. Remove Covers and Connect Wires

Carefully take off the top and bottom covers of the sensor.
Connect the wires neatly and guide the thread end out through the threaded port.

2. Position and Mark Holes

Determine the appropriate installation position and ensure the transmitter and receiver are aligned in parallel.
Mark the hole positions on the wall for accurate drilling.

3. Drill and Fix

Use a percussion drill to create holes at the marked locations on the wall.
Insert wall plugs into the holes and secure them firmly with screws.

4. Mount Transmitter and Receiver

Use M3*25 screws to mount the transmitter and receiver on the wall.
Connect the power supply and check the alignment of the sensor.
If necessary, adjust the angle by rotating the aluminum tube. Once aligned properly, lock the rotating screw securely.

5. Replace Covers and Final Testing

Secure the top and bottom covers of the sensor using M2*8 screws.
Conduct a final test to confirm that the sensor is operating correctly.

FAQs:

Q: What are some common installation issues?
A: Our FAQ section addresses potential installation issues such as improper alignment, difficulty in drilling, or wire connection problems. We provide detailed solutions to help you streamline the installation process and overcome these challenges.

Q: How can I troubleshoot if the sensor is not working correctly?
A: Our FAQ includes comprehensive troubleshooting tips. If the sensor is not functioning as expected, check the power supply connection, alignment of the transmitter and receiver, and ensure that there are no obstructions interfering with the infrared beams. Follow the step-by-step troubleshooting guide to resolve any issues you may encounter during installation or operation.

Package

Before introducing the functional advantages of our products, we also present the detailed product packaging details of Jutai infrared curtain photocell to you.

Advantages

JUTAI Curtain Photocell Advanced Function we list as followings

Using unique infrared technology, it can be used under direct sunlight; it has a stable detection distance of 20 meters.

Anti-Theft High of 100cm Curtain Photocell Beam Sensor for Home Security

Company Profile

JUTAI is a renowned manufacturer of Motion Sensor Photoelectric Sensors, recognized for its seamless integration of research, development, production, sales, and distribution. Our foundation rests upon innovation and an unyielding dedication to quality, aimed at providing outstanding solutions to our esteemed clientele. As we propel forward in establishing our brand, we aspire to serve as your trusted production partner in your quest to build and promote your own brand.

With over a decade of experience in research and production, we have amassed a wealth of expertise in wireless communication technology, automatic door sensors, and wholesale distribution of barrier gates. Our core product portfolio encompasses a diverse array of offerings, including:

Automatic door sensors
Microwave radar sensors for automatic doors
Infrared sensor series
Loop detectors
Short, medium, and long-range wireless RFID card readers
Barrier gates
Parking barrier gates

Every JUTAI hardware product is meticulously crafted to seamlessly integrate with access control systems, providing comprehensive solutions for access control, parking management, and parking guidance systems.
