M8 Terminal Type LiFePO4 Lithium Battery ECOLTO-24200 IP65 Housing Protection

Price Negotiable

Price: Inquiry

MOQ: 1000pcs

Delivery Time: 5-8 work days

Brand: Ecolite

Product Description

ECOLTO-24200

information
Start a Free Product Chat

ECOLTO-24200

Lithium Iron Phosphate Battery

1)Quick Details

Deep cycle Lithium battery (LiFePO4) 24V200Ah

2)Features

Lithium-ion batteries are now a very popular type of battery.Long life Deep cycle ＞ Capacity upgrade to store more capacity and longer use time. Variety of charging methods: solar panels, electric supply, engine charging
Our products support customization, factory direct sales, brand cell, intelligent BMS, mature and reliable production process.

3)Application

Home energy storage, solar energy storage,RV,Marine propeller,Outdoor high power equipment,UPS

Product Parameter
Start a Free Product Chat

Electrical Parameters		Mechanical Parameters
Nominal Voltage	25.6V	Dimension(L×W×H)	640x245x220mm
Rated Capacity	200Ah	Dimension(L×W×H)	25.19x9.64x8.66"
Energy	5120Wh	Weight	42kg
Resistance	≤ 65mΩ	Terminal Type	M8
Efficiency	0.99	Battery Housing	ABS
Cycle Life	>4000cycles @1C,80% DOD	Housing Protection	IP65
Self Discharge	2% per Month	Cell Type-Chemistry	LiFePO₄Cell
Max. Modules in Series/Parallel	8S/4P	SOC Display(Optional)	/
Discharge Parameters		Charge Parameters
Continuous Discharge Current	100A	Charge Method	CC-CV
Pulse Discharge Current	200A (<3S)	Charge Voltage	28.4-29.2V
Recommended Volt. Disconnect	20V	Recommended Float Voltage	27V
BMS Discharge Cut-off Voltage	17.6V	Recommended Charge Current	50A
Reconnect Voltage	21.6V	Maximum Charge Current	100A
Short Circuit Protection	300-800us	BMS Charge Cut-off Voltage	30V
Temperature Parameters
Discharge Temperature	-20 to 60 ℃
Charge Temperature	0 to 60 ℃
Storage Temperature	-10 to 60℃
BMS High Temperature Cut-off	65 ℃
