Rental LED Screen Intdoor P3.9 500*1000mm Led Screen For Stage
Seamless high-definition, ultimate display.
Seamless high-definition display eliminates visible gaps, providing a large and uninterrupted viewing area, with an ultra-wide 160° viewing angle;
Low brightness, high grayscale, and high refresh rate ensure stable dynamic images without ripples or flickering,
delivering clear image edges and a more comfortable visual experience.
High flatness, excellent heat dissipation.
Die-cast aluminum cabinet material with a unique heat dissipation design ensures safe and stable operation;
Board-to-board hard connection for connectors, with separate designs for power and signal transmission, offering reliability and stability.
Convenient installation and maintenance.
Flexible installation and maintenance, with front maintenance support for modules. The cabinets support various installation methods, including back frame mounting and stacking;
The cabinets are designed with recessed and protruding steps on the sides for lateral alignment, preventing front-to-back misalignment during installation. Quick-locating pins on the top and bottom of the cabinets ensure proper alignment to prevent vertical misplacement during assembly.
| Model | 1.9i | 2.6i | 2.9i | 3.9i | 4.8i |
| Pixel Pitch(mm) | P1.9 | P2.6 | P2.9 | P3.9 | P4.8 |
| Pixel Density(dot/㎡) | 262,144 | 147,456 | 112,896 | 65,536 | 43,264 |
| LED Type | SMD1515 | SMD2121 | SMD2121 | SMD2121 | SMD2121 |
| Module Size(mm*mm) | 250*250 | 250*250 | 250*250 | 250*250 | 250*250 |
| Cabinet Size(mm*mm*mm) | 500*500 | 500*500/500*1000 | 500*500/500*1000 | 500*500/500*1000 | 500*500/500*1000 |
| Cabinet Resolution(dot*dot) | 256*256 | 192*192/192*384 | 168*168/168*336 | 128*128/128*256 | 104*104/104*208 |
| Cabinet Material | Die-cast Aluminum | Die-cast Aluminum | Die-cast Aluminum | Die-cast Aluminum | Die-cast Aluminum |
| Cabinet Weight(kg) | 7.5 | 7.5/12 | 7.5/12 | 7.5/12 | 7.5/12 |
| Brihtness(cd/㎡) | 800~1000 | 800~1000 | 800~1000 | 800~1000 | 800~1000 |
| Refresh Rate(hz) | 1920~3840 | 1920~3840 | 1920~3840 | 1920~3840 | 1920~3840 |
| Gray Scale(bit) | 14 | 14 | 14 | 14 | 14 |
| Viewing Angle(deg) | H 160/V140 | H 160/V140 | H 160/V140 | H 160/V140 | H 160/V140 |
| Max Power Consumption(w/㎡) | 440 | 440 | 440 | 440 | 440 |
| Ave Power Consumption(w/㎡) | 132 | 132 | 132 | 132 | 132 |
| Input Voltage(V) | 100~240 | 100~240 | 100~240 | 100~240 | 100~240 |
| Working Temperature(℃) | -20~+60 | -20~+60 | -20~+60 | -20~+60 | -20~+60 |
| Operation Humidity(rh) | 10%~90% | 10%~90% | 10%~90% | 10%~90% | 10%~90% |
| Ingress Pritection | IP65 | IP65 | IP65 | IP65 | IP65 |
| Working Environment | Indoor | Indoor | Indoor | Indoor | Indoor |
| Life Span(H) | 100,000 | 100,000 | 100,000 | 100,000 | 100,000 |
| Certificate | CE/ETL/FCC | CE/ETL/FCC | CE/ETL/FCC | CE/ETL/FCC | CE/ETL/FCC |
