Mild Steel Horizontal Vacuum Belt Filter 20m2 High Automatic Control for Power Plant Sludge Dewatering
Mild Steel Painting Horizontal Type Vacuum Belt Filter High Automatic Control For Power Plant
1. Brief Instroduction
Vacuum belt filters are ideal for filtration processes that involve the presence of heavy solids and large filtration surfaces.
These filters are a subcategory of horizontal vacuum filters, with which they share great flexibility and a high filtration rate.
The main feature of the belt filter system is the additional presence of the filtration cloth and a special reinforced rubber belt with draining grooves.
2. Application
The vacuum belt filter is mainly used for dewatering of sludge and slurry and juice extraction from apples, pears and other fruits, as well as grapes for winemaking, etc. Belt filters are used both municipally and industrially in a range of areas including urban sewage and wastewater treatment, metallurgy and mining, steel plants, coal plants, breweries, dyeing, tanneries, as well as chemical and paper factories.
3. Features
| Assembled frame block-design |
| High automatic control |
| Reduce operation cost |
| Reduce the working strength of labors |
| Improve working enviroment |
| High filtration speed |
| Good washing quality |
| Lower moisture content |
4. Structure of Belt Filter
| 1 | Filter Cloth Washing | 8 | Filter Cloth Tension Unit |
| 2 | Belt Washing | 9 | Discharge Roll |
| 3 | Cake Washing Box | 10 | Drive Pulley |
| 4 | Slurry Feeding Hopper | 11 | Driven Pulley |
| 5 | Rubber Belt | 12 | Vacuum Box |
| 6 | Filter Cloth | 13 | Filter Support Frame |
| 7 | Filter Cloth Tracking Unit |
5. Packing and Delivery
UNIVEE has rich experiences of products packing, loading and delivery for mutli-transporation.
Type of Packing:
| Packed in Crate / Wooden Case / Tin Lined Wooden Case / Plywood Case. |
| Packed with fumigation package |
| Packed in plastic lorap, double bister and jute rope |
6. FAQ
Q1: What is vacuum belt filter?
A common piece of industrial equipment used in solid-liquid separation processes, such as sludge dewatering in the water and wastewater treatment industries, is the vacuum filter. The most popular filtering technique involves passing a series of filtering belts or cloth through a roller unit.
2) What is the purpose of a vacuum belt filter?
Water is removed from liquid wastewater residuals using belt filter presses, which creates “cake,” a non-liquid substance. Dewatering wastewater solids improves operation, lowers costs for further storage, processing, transfer, end use, or disposal, and decreases the volume of residuals.
3) What are the types of vacuum belt filter systems?
Mechanical, biological, and chemical filtration are the three basic forms of filtering.
