China 4 in 1 Laser Cleaning Welding Cutting Machine with Double Wobble Auto Wire Feeder and Handheld Laser Welder for sale

4 in 1 Laser Cleaning Welding Cutting Machine with Double Wobble Auto Wire Feeder and Handheld Laser Welder

Price Negotiable
Price: CN¥3,602.30/pieces >=1 pieces
MOQ: Negotiable
Delivery Time: Negotiable
Product Description



Laser welding machine parameters
Model
HM-1000
HM-1500
HM-2000
HM-3000
Laser Source
Everfoton/Raycus/MAX/BWT
Everfoton/Raycus/MAX/BWT
Everfoton/Raycus/MAX/BWT
Everfoton/Raycus/MAX/BWT
Laser Power
1000w
1500w
2000w
3000w
Laser Source Type
CW Fiber Laser
CW Fiber Laser
CW Fiber Laser
CW Fiber Laser
Power Adjustment Range
10-100%
10-100%
10-100%
10-100%
Laser Wavelength
1080±10nm
1080±10nm
1080±10nm
1080±10nm
Modulation Frequency
20khz
20khz
5khz
5khz
Laser Welding Head
Super/Relfar
Super/Relfar
Super/Relfar
Super/Relfar
Welding Speed
0-120mm/s
0-120mm/s
0-150mm/s
0-150mm/s
Scan Width Adjustable
0.1~6mm
0.1~6mm
0.1~6mm
0.1~6mm
Gas Requirements
10-15L/min(Ar/N2)
10-15L/min(Ar/N2)
10-15L/min(Ar/N2)
10-15L/min(Ar/N2)
Cooling Method
Air Cooling
Water Cooling
Water Cooling
Water Cooling
Optical Cable Length
7m/10m/15m
7m/10m/15m
7m/10m/15m
7m/10m/15m
Operating Voltage
AC220V 50/60Hz
AC220V 50/60Hz
AC220V 50/60Hz
AC380V 50/60Hz
Ambient Temperature
10~45 ℃
10~45 ℃
10~45 ℃
10~45 ℃
Environment Humidity
10%-85%
10%-85%
10%-85%
10%-85%
Energy Consumption
3.8KW
5.5KW
7.0KW
10KW
Machine Size
1000mm*650mm*720mm
1000mm*650mm*720mm
1000mm*650mm*720mm
1140mm*750mm*1050mm
Net Weight
105kg
110kg
120kg
175kg
Wire Feeding Diameter
0.8mm/1.0mm/1.2mm/1.6mm
0.8mm/1.0mm/1.2mm/1.6mm
0.8mm/1.0mm/1.2mm/1.6mm/2.0mm
0.8mm/1.0mm/1.2mm/1.6mm/2.0mm
