Flame Retardant Conductor Hydraulic Cable Tensioner Stringing Equipment
Overhead Line Construction Cable Stringing Equipment Transmission Power Line Hydraulic Puller Tensioner
Our MAR-YZ40A Hydraulic Tensioner is designed to facilitate the tension stringing operation for various steel wire ropes, conductors, and earth wires. It features a bullwheel lined with durable and abrasion-resistant MC nylon material, with an ultra-wide groove spacing for enhanced versatility.
One of its standout features is its ability to achieve constant-tension conductor stringing, thanks to its infinitely variable tension control mechanism. This ensures precise control throughout the stringing process, maintaining the integrity of the installation.
Safety is paramount, and in the event of hydraulic failure, our tensioner is equipped with a spring-applied hydraulically released multi-plate brake. This safety mechanism engages automatically, guaranteeing safe operation and preventing accidents.
Furthermore, our MAR-YZ40A Hydraulic Tensioner includes a hydraulic-power output interface. This interface is specifically designed to seamlessly connect with the shaft bracket of hydraulic wire equipment, enhancing efficiency and compatibility in your operations.
For reliable and efficient tension stringing operations, trust in the performance and safety features of our MAR-YZ40A Hydraulic Tensioner.
Uses: It's used for stringing various steel wire ropes, conductors and earth wires.
Here's an alternative expression of the features:
1. Durable Bull Wheel: Equipped with wear-resistant MC nylon lining segments, the bull wheel ensures lasting performance under demanding conditions.
2. Flexible Tension Control: Enjoy precise tension adjustments with infinite variability, enabling consistent tension control for conductor stringing, maintaining optimal installation quality.
3. Automatic Safety Brake: In the event of hydraulic failure, the spring-applied hydraulic release brake engages automatically, swiftly halting operations to uphold safety standards.
4. Convenient Power Output Interface: Seamlessly connect to hydraulic conductor reel stands with the attached hydraulic power output interface, facilitating efficient workflow integration.
Main Components
| Model | SA-YZ40 Hydraulic Tensioner |
| Maximum Tension (kN) | 40 |
| Continuous Tension (kN) | 35 |
| Maximum Speed (km/h) | 5 |
| Bullwheel Bottom of Groove Diameter (mm) | Φ1200 |
| Number of Grooves | 5 |
| Maximum Pullback (kN) | 40 |
| Maximum Speedback (km/h) | 3 |
| Maximum Diameter of Suitable Conductor (mm) | Φ32 |
| Engine Power / Speed (kW/rpm) | 51/2500 |
| Dimensions (mm) | 3400× 1800× 2400 |
| Weight (kg) | 2800 |
| Engine | Beinei Deutz air cooled diesel engine |
| Main Pump/Motor | Rexroth |
| Reducer | RR (Italian) |
| Main hydraulic valve | Rexroth |
Marshine Power offers a comprehensive range of transmission support equipment, including Tubular Gin Poles, Hydraulic Cable Pullers, Wire Rope Pulley Blocks, Hoisting Tackles, Wire Rope Grippers, Cable Reel Spools, and Stands. Our products are OEM and manufactured to the highest standards in compliance with ISO 9001:2008. Trusted by customers in over 50 countries worldwide, we ensure reliability and performance in every product.
Customization is available for specialized items such as emergency restoration towers and crossing structures. Additionally, our safety tools and accessories have no minimum order quantity requirements, ensuring accessibility for all your needs.
Whether you require technical assistance or have specific product requirements, our team is dedicated to providing solutions tailored to your needs. Feel free to reach out to us for any inquiries or assistance. Thank you for considering Marshine Power as your transmission support partner.
1. Training and services.
Marshine is a company specializing in the development, design and manufacture of electrical construction equipment and tools. We not only manufacture and sell international standard products, OEM and custom products, but also provide quality tracking and service monitoring.
2. How about the quality of your products?
Our products are manufactured in strict accordance with national and international standards, and each product is tested before delivery. If you would like to view our quality certification and various test reports, please consult us.
3. Why do you choose us?
Because we can provide you with excellent service, quality and reasonable price. In addition, we can also provide smooth delivery of goods, excellent customer solutions.
4. Customer inquiry.
If there is an emergency, customers can also use online contact methods (online Chat, Skype, WhatsApp, wechat) for faster and better communication. Any enquiry will be answered within 12 working hours.
5. How to obtain samples?
We can provide free samples to the buyer for testing, but the buyer needs to pay the freight. Existing samples take 2-3 days. If there is no stock, we will advise the delivery date.
6. How about packing and shipping?
All goods will be packed in plywood boxes for safe, long haul transport. Support EXW, FOB, CIF, CFR terms.
Required documents such as packing list, commercial invoice, bill of lading, air waybill, CO, Form E, Form F etc will be provided.
Note: If you do not find the product you need, please feel free to contact us. We will provide the best quotation as soon as we verify your requirements.
