Hydraulic Conductor Tensioner Cable Tensioners Stringing Equipment Transmission Power Line
20 Ton Hydraulic Conductor Tensioner Cable Tensioners Stringing Equipment Transmission Power Line Hydraulic Puller Tensioner For Pulling
Uses : it's used for stringing various conductors and earth wires.suitable for stringing two bundle conductors or four bundle conductors
Feature:
The bull wheel is equipped with MC nylon lining segments, ensuring wear resistance. Enjoy precise tension control with an infinitely variable system, ensuring constant tension conductor stringing. Safety is ensured with the automatic engagement of the spring-applied hydraulic release brake in the event of hydraulic failure. Easily connect hydraulic conductor reel stands via the attached four sets of hydraulic power output interfaces, enhancing operational flexibility.
Main component
| Engine | Cummins(USA) water cooled diesel engine . |
| .Main pump/motor | Rexroth |
| Main hydraulic valve | Rexroth |
| Reducer | RR (Italian) |
Essential parameter
Maximum Tension(kN):4×50 or 2×100
Continuous Tension(kN):4×45 or 2×90
Maximum speed (km/h):5
Bull wheel bottom of groove diameter(mm):Φ1600
Number of grooves:4×5
Maximum pull-back (kN):4×50 or 2×100
Maximum pull-back speed(km/h):4×1.5
Maximum suitable conductor diameter (mm): Φ42.5
Engine power /speed (kW/rpm):78/2500
Dimensions (mm): 5350×2350×2900
Weight(kg):12000
Marshine Power provides essential equipment for transmission work, including Tubular Gin Poles, Hydraulic Cable Pullers, Wire Rope Pulley Blocks, Hoisting Tackles, Wire Rope Grippers, and Cable Reel Spools and Stands. Our products are OEM and manufactured to the highest standards, meeting ISO 9001:2008 requirements.
With a global presence in over 50 countries, Marshine Power is trusted by customers worldwide. We offer customization options for items like emergency restoration towers and crossing structures to meet specific project needs. Additionally, our safety tools and accessories have no minimum order quantity requirement.
Whether you have technical issues or specific product requirements, our team is here to assist you. Feel free to reach out to us for any inquiries or assistance you may need. Thank you for considering Marshine Power for your transmission work needs.
1. Training and services.
Marshine is a company specializing in the development, design and manufacture of electrical construction equipment and tools. We not only manufacture and sell international standard products, OEM and custom products, but also provide quality tracking and service monitoring.
2. How about the quality of your products?
Our products are manufactured in strict accordance with national and international standards, and each product is tested before delivery. If you would like to view our quality certification and various test reports, please consult us.
3. Why do you choose us?
Because we can provide you with excellent service, quality and reasonable price. In addition, we can also provide smooth delivery of goods, excellent customer solutions.
4. Customer inquiry.
If there is an emergency, customers can also use online contact methods (online Chat, Skype, WhatsApp, wechat) for faster and better communication. Any enquiry will be answered within 12 working hours.
5. How to obtain samples?
We can provide free samples to the buyer for testing, but the buyer needs to pay the freight. Existing samples take 2-3 days. If there is no stock, we will advise the delivery date.
6. How about packing and shipping?
All goods will be packed in plywood boxes for safe, long haul transport. Support EXW, FOB, CIF, CFR terms.
Required documents such as packing list, commercial invoice, bill of lading, air waybill, CO, Form E, Form F etc will be provided.
Note: If you do not find the product you need, please feel free to contact us. We will provide the best quotation as soon as we verify your requirements.
