Industrial Food Wood Dryer Machine Heat Pump Pepper Fruit Chrysanthemum Drying

Food Wood Dryer Machine Pepper Fruit Heat Pump Drying Chrysanthemum

Product introduction:
During the drying process of the dryer, the hot airflow moves forward from the tail, fully contacts the material, and makes full use of the heat transfer through heat conduction, convection, and radiation; the heat energy is directly transferred to the material, so that the moisture of the material is continuously evaporated in the cylinder. , the air induction device at the feed inlet extracts a large amount of water and wet air flow to prevent secondary pollution caused by dust discharge, and can dry vegetables, fruits, medicinal materials, wood, flowers, meat, seafood and other principles.

Working principle:
The main principle of heat pump application in drying process is to use the heat pump evaporator to absorb the heat energy in the outside air, or to recover the waste heat of the exhaust gas during the drying process, and then transfer (transfer) the energy to the drying room through the work of the compressor. The materials in the drying room vaporize and evaporate the moisture in the materials through circulating hot air heat transfer. The evaporated water vapor is drained or the cold water flows out to achieve the purpose of drying the materials. The refrigerant after condensing the heat is After passing through the throttle valve, it becomes a low-temperature and low-pressure liquid. Due to the sudden drop in pressure, the wave-like refrigerant enters the evaporator and continuously absorbs the low-level heat energy of the surrounding air and quickly evaporates into a gaseous state. The refrigerant that has absorbed a certain amount of energy flows back to the compressor and enters the evaporator. Next cycle. In this way, the refrigerant is continuously circulated to transfer the heat in the air to the drying room to heat the air temperature in the room.

Advantage:
1. Various hanging rails, floor rails and other hanging methods and spraying scenarios can be customized according to customer workpieces.
2. The fireproof and thermal insulation exterior wall rock wool board is made of 10mm fireproof rock wool insulation board.
3. Fully electric operation, no pollution to drying materials and external environment, greatly improving the working environment.


Dryer machine specification:
