Horizontal Waste Paper Hydraulic Baler Plastic Bottle Baler Machine

Price Negotiable
Price: Negotiable
MOQ: 1 set
Delivery Time: 5-7 work days
Brand: TONTEN
Product Description

Horizontal Waste Paper Hydraulic Baler Plastic Bottle Baler Machine



Product introduction:
Horizontal baler can process a large amount of recyclable materials such as paper, cardboard, plastic, metal and other classified waste. It is a packaging machine with mechatronics and a high degree of automation, mainly composed of mechanical system, control system, feeding system and power system, etc. The whole packaging process consists of pressing bag, return, tote, transfer box, bag out, bag out and packaging. Make your waste management a simple and economical process. It is an important waste baler equipment in the waste sorting line.



Advantages:
1. The horizontal baler uses a copper core motor with strong power, and the long-term operation of the Tai Chi turbine rotation can effectively reduce noise
2. The hydraulic baler has strong applicability and can compress a variety of materials such as cartons, empty bottles, straw, iron scraps, scrap metal, cans, plastics, etc.

3. The hydraulic baler uses hydraulic power, low-noise hydraulic circuit design, gear pump for long-term oil supply, simple installation, no foundation required
4. The frame is made of high-quality steel, which will not deform after long-term use. The warp and weft lines of the frame are superimposed, and the strength is high without welding



Specification:

Model

80

120

160

180

Power(kw)

18+4

22+11

22+15

30+18.5

Oil pump

63

63+40

63+63

100+63

Cylinder(t)

100-130

150-180

200-300

280-300

Dimensions(m)

5.6*1.5*1.5

6.5*1.5*2.5

8.5*1.6*3.65

9*1.6*4.2

Baling size(mm)

1300*800*900

1500*900*1100

1500*1100*1200

1500*1100*1300

Mouth size(mm)

1400*800

1500*900

1600*1100

1800*1100

Bale weight(kg)

500

1000

1300

1500

Capacity(bale/h)

4-7

5-10

5-10

5-10

Bale line

5

5

5

5

Nominal thrust(kn)

800

1200

1600

1800

System pressure(mpa)

25-28

25-28

28.5

28.5
