BEXKOM Push pull circular connectors 2~48pins EMC shielding IP50 to IP68 waterproof size 00 to size 4 with cable assembly
Price:
Negotiable
MOQ:
5 pcs
Delivery Time:
1 week
Brand:
BEXKOM
Product Description
BEXKOM Push Pull Circular Connectors
High-quality circular connectors with 2~48 pins featuring EMC shielding, IP50 to IP68 waterproof ratings, and sizes 00 to 4 with cable assembly options.
Technical Specifications
| Specification | Details |
|---|---|
| Pin Numbers | 2~48 |
| Shell Material | Brass Chrome Plated |
| Pin Material | Brass Gold Plated |
| Insulator Material | PPS/PEEK |
| Waterproof Level | IP50 |
| Work Temperature | -55°C to 250°C |
| Salt Spray Corrosion Resistance | 96 Hours |
| Mating Cycles | >5000 times |
| Current Rate | 1.5 - 25 A |
| Testing Voltage | 450~2100V |
| EMC Shielding | Available |
| Locking Method | Push Pull Locking |
| Shock Resistance | 100g/6ms |
| Vibration Resistance | 10~2000Hz, 15g |
Metal and plastic shell circular connector with brass chrome-plated shell and gold plated contacts for medical and industrial applications.
This high-quality circular connector features a metal shell constructed from brass with durable chrome plating, offering superior corrosion resistance and professional aesthetic finish. Engineered for high-end applications, it provides exceptional EMC 360-degree shielding to protect sensitive electronics from electromagnetic interference in demanding environments.
The connector boasts an IP-rated waterproof design, ensuring reliable performance in harsh conditions and moisture-prone settings. Its innovative push-pull locking mechanism enables quick, tool-free mating and unmating while maintaining a secure connection under vibration or mechanical stress.
Compatible with industry-standard circular connector interfaces (including LEMO, ODU, and Fischer series), this solution is ideal for mission-critical applications in aerospace, MIL, medical equipment, industrial automation, and high-end telecommunications. The combination of rugged construction, advanced shielding, and ergonomic design makes it a top-tier choice for engineers prioritizing durability, signal integrity, and user convenience.
Key Features
- Material: Brass metal shell with chrome plating or plastic shell
- Contact: Brass gold plated
- Insulator: PPS or PEEK
- Waterproof level: IP50 to IP68
- MOQ: 5pcs
- Shielding: EMC protection (Plastic: No)
- Environmental: Waterproof
- Mechanism: Push-pull locking for secure mating
- Applications: High-reliability industrial/medical use/New energy
