36KW EVI Heat Pump Side Discharge 3N 380V 50HZ Plate Heat Exchanger Suitable for Industrial and Commercial Heating,heat pump water heaters
36KW EVI Heat Pump Side Discharge 3N 380V 50HZ Plate Heat Exchanger
36KW EVI heat pump side discharge 3N 380V 50HZ plate heat exchanger designed for efficient heating solutions.
Scientific research shows that from the perspective of health and comfort, the ideal temperature in winter is between 18-20°C. The ideal heat distribution shows a temperature distribution from floor to ceiling with vertical reduction, which can keep the feet warm and clear-headed.
The heat of floor heating rises from the foot, creating a hierarchical temperature distribution throughout the indoor space. This conforms to the traditional Chinese medicine health principle of "warm and cool." Floor heating is an ideal heating method without hot air, which helps maintain body moisture while providing benefits for rheumatism and asthma conditions.
- Timer and clock function
- Multiple protection systems
- Automatic and forced defrost
- Anti-freezing function
| Model | M-D36AAH | |
|---|---|---|
| Heating Capacity Range | kW | 36 |
| Heating Capacity Range | BTU/h | 122,832 |
| Heating Power Input Range | kW | 9.47 |
| Cooling Capacity Range | kW | 21.6 |
| Cooling Capacity Range | BTU/h | 73,699 |
| Cooling Power Input Range | kW | 8.7 |
| Frequency | Hz | 50 |
| ErP level (35℃) | / | A++ |
| ErP level (55℃) | / | A+ |
| Power Supply | / | 3N 380V 50HZ |
| Electric Heater | kW | / |
| Max. Running Current | A | 21.8 |
| Refrigerant Type | / | R410A |
| Refrigerant Quantity | kg | 3.1 |
| Water Connection | / | 1" |
| Water Pressure Drop | kPa | 10 |
| Water Pump Head | m | 11.8 |
| Fan Motor Quantity | / | 2 |
| Motor Power Input | W | 220 |
| Fan Speed | rpm | 850 |
| Noise | dB(A) | 58 |
| Net Weight | kg | 202 |
| Gross Weight | kg | 254 |
| Net Dimension (L/W/H) | mm | 1370*580*1525 |
| Shipping Dimension (L/W/H) | mm | 1480*690*1690 |
| Operation Ambient Temp. | ℃ | -25~43℃ |
Under ideal weather conditions, heat pump water heaters produce three times the energy used to power the heat pump. In other words, heat pump water heaters use one-third of the electricity of conventional electric water heaters. CUB estimates that the average residential customer would save significantly per month using a MEIDIBAO heat pump water heater.
