4 Core ECCS Corrugated Steel Armored Fiber Optical Cable 8.2mm HDPE Rodent Resistant
Price:
Negociation
MOQ:
1000M
Delivery Time:
According to the quantity
Brand:
AMD
Product Description
4 Cores ECCS Corrugated Steel Armored Fiber Optical Cable 8.2mm HDPE Rodent Resistant
4 Cores ECCS Corrugated Steel Armored Fiber Optical Cable 8.2mm HDPE Rodent Resistant Steel Tape
Corrugated steel armored fiber cables are suitable for outdoor use, because armored fiber cables are water blocking, wear-resisting, and can take temperature fluctuations, then are often used for outdoor communication networks, industrial and infrastructure projects.
Cable Parameter
| Items | Specifications | |
| Fiber Count | 4 | |
| Tight-buffered Fiber | Dimension | 0.75mm±0.05mm |
| Material | PVC | |
| Color | Blue, Orange,Green,Brown | |
| Inner Jacket | Dimension | 3.8 mm±0.1mm |
| Material | LSZH | |
| Color | Black | |
| Outer Jacket | Dimension | 8.2mm±0.3mm |
| Material | HDPE | |
| Color | Black | |
Mechanical and Environmental Characteristics
| Items | Unit | Specifications |
| Tension(Long Term) | N | 500 |
| Tension(Short Term) | N | 800 |
| Crush(Long Term) | N/10cm | 300 |
| Crush(Short Term) | N/10cm | 1000 |
| Min. Bend Radius(Dynamic) | mm | 20D |
| Min. Bend Radius(Static) | mm | 10D |
| Installation Temperature | ℃ | -40～+70 |
| Operating Temperature | ℃ | -40～+70 |
| Storage Temperature | ℃ | -40～+70 |
Cable can comply with following standards,
Torsion Resistance IEC 60794-1-2-E7
Tensile Force IEC 60794-1-2-E1,
Water penetration IEC 60794-1-2-F5 C
Crush Resistance IEC 60794-1-2-E3
UV Resistance ASTM G154-16,
Exposure 720 hrs, IL≤0.05dB 6 Cycles
Anti-Rodent Cable should be rodent bite-proof
Kink Resistance IEC 60794-1-2-E10, 10xD,
