IP54 Outdoor Protection 120kW DC Fast EV Charger with 200-750V Output Voltage for Electric Vehicles
Price:
Negotiate
MOQ:
1
Delivery Time:
Negotiable
Brand:
Mckee Charging Cube
Product Description
The charger supports flexible charging configurations, including fast single-gun charging and simultaneous multi-gun charging with balanced output. Through automatic vehicle identification, the system establishes real-time communication with the vehicle's Battery Management System (BMS), ensuring precise power control and improved charging safety.
Manufactured under strict quality control standards, the charger's metal enclosure is designed for strength, durability, and visual consistency. The surface coating is smooth and uniform, free from defects that could affect performance or appearance. Mechanical strength meets GB/T 18487.3 requirements, ensuring structural stability during long-term operation.
With full compliance to GB/T charging interface and communication standards, combined with IP54 protection, this charger is suitable for demanding outdoor environments such as transportation hubs, fleet charging facilities, and infrastructure projects.
Product Features
- Intelligent DC fast charging with automatic BMS matching
- Supports single and multi-gun charging with balanced power output
- High-strength steel cabinet with IP54 outdoor protection
- Real-time monitoring via integrated HMI display
- Emergency stop and multi-level electrical protection
- Reinforced mounting design for secure installation
- Compatible with 12V and 24V auxiliary power systems
Technical Parameters
| Place of Origin | Luoyang, China |
| Interface Standard | CCS1/CCS2/CHAdeMO/GB/T |
| Input Voltage | 380V±15% |
| Power Frequency | 50Hz |
| Output Voltage Range | 200-750V |
| Output voltage accuracy | ±0.5% |
| Cable length | 5 Meters, support customized |
| IP Grade | IP54 |
| Function | Energy Vehicle Charging |
| Operating Temperature | -30℃~+50℃ |
Applications
The Mckee 120kW DC Fast Charger is suitable for a wide range of EV charging scenarios:
- Public charging stations - High-speed charging for busy urban or suburban areas
- Commercial parking lots & shopping centers - Increase customer convenience and traffic
- Fleet depots for buses, taxis, logistics vehicles - Rapid turnaround and high operational efficiency
- Highway service areas - Enable long-distance EV travel with reliable fast charging
- Energy companies & infrastructure projects - Expand charging networks with stable, scalable hardware
Designed for high reliability and low maintenance, it is the perfect choice for operators seeking performance, safety, and long-term value.
FAQ
Q1: Which charging standards are supported?
A1: CCS1, CCS2, CHAdeMO, and GB/T--compatible with most global EV models.
Q2: Is the charger suitable for outdoor installation?
A2: Yes. IP54-rated protection ensures stable performance in rain, dust, heat, and cold.
Q3: What power configurations are available?
A3: 60kW, 120kW, and 180kW, suitable for both small and large-scale charging projects.
Q4: Does it support payment systems?
A4: Yes. RFID card, APP control, and OCPP-based cloud management are optional.
Q5: How long is the delivery time?
A5: Standard models ship within 3-10 days; custom configurations depend on order requirements.
