60kW DC Fast Charging Pile for Electric Vehicles, equipped with an LCD display, providing efficient and rapid EV charging solutions.
Price:
Negotiate
MOQ:
1
Delivery Time:
Negotiable
Brand:
Mckee Charging
Product Description
60kW DC fast charger for electric vehicle charging stations, equipped with dual charging guns, a 7-inch high-brightness colour touchscreen, and IP54 protection rating
IP54 protection rating, 7-inch high-brightness color touch screen, multiple protection functions
Product Overview
This integrated DC charger enables single-gun fast charging, rapid recharge, and simultaneous charging of four guns with average power distribution. It automatically identifies and provides power to the vehicle's BMS system.The charger meets strict appearance quality standards including paint, coating quality, color consistency, and product markings. All metal components are smooth with no sharp edges, burrs, cracks, or defects. Surface coatings are uniform, bright, and free from wrinkles, flow marks, or peeling.Mckee Intelligent Technology complies with GB/T 20234.3-2015, GB/T 18487.1-2015, GB/T 18487.3-2001 standards for charging interfaces and systems, and follows GB/T 27930-2015 for communication protocols between chargers and vehicle BMS
Key Features
- Side panel includes touch screen, charging indicators, fault indicators, emergency stop button, and nameplate
- Robust construction withstands mechanical stress without deformation
- Pre-drilled mounting holes for secure installation
- Supports 12V and 24V auxiliary power connections
- Equipped with charging plugs and cable storage devices for convenient access
Technical Specifications
| Place of Origin | Luoyang, China |
|---|---|
| Output Power | 60KW |
| Interface Standard | CCS1/CCS2/CHAdeMO/GB/T |
| Output Current | 250A |
| Input Voltage | 380V |
| Application | Electric Vehicle Charging |
| Warranty | 2 Years |
| Cable Length | 5 Meters (customizable) |
| IP Grade | IP54 |
| Additional Features | APP Control, RFID Card Optional |
About McKee
Mckee is a manufacturer focusing on electric car charging stations and related electric car accessories. Committed to sustainable development since 2011, we constantly aim to adopt clean and green technologies, striving to provide safe and green energy services through technological innovation.
We provide complete electric vehicle charging solutions, from innovative energy storage technology to public DC fast charging stations, fast charging stations and portable charging stations for home use. Our infrastructure can meet every type of demand.
Frequently Asked Questions
How long is your delivery time?
For charging posts, it is usually 3-10 days. If there is no stock, the production lead time is determined according to the order quantity. High-power DC charging posts usually need to be customized according to the customer's technical parameters.
How long does it take to customize the prototype?
For charging piles, the prototype time is usually 7 days. For DC charging posts, the prototype time is usually 15 days. For high power fast charging stations, the technical parameters need to be determined before production, and the prototype time is usually 30 days.
How to guarantee the service?
Our products are divided into two categories: household and commercial. For home chargers, we provide standardized service: 1 year warranty + remote installation and usage guidance + video installation tutorial. For commercial chargers, we provide both standardized services and payment software docking services for operating companies.
How do you guarantee the quality of your products?
The charging post products we sell have passed GB certification in China and CE certification in EU. For some other countries, the relevant certifications are in progress.
Additional Information: OEM supported. Any requirement please contact us to talk about the details. We will reply to your inquiry within 24 hours. The above for reference only, final price determined by charger KW - please contact us for accurate quote.
