High Zirconia Fused Cast Brick with Refractoriness Degree 1770° Refractoriness 2000°
High Zirconia Fused Cast High
Zirconia Brick used for glass furnace with factory price
Description of Fused Cast High Zirconia Brick
The series of HT-Fused cast high zirconia brick is fused cast high zirconia refractories which are specially designed refractory for glass furnace application. Fused cast high zirconia brick is made of artificial synthesis high purity raw materials through special casting process. The crystalline texture consists of baddeleyite and with the characteristics of excellent high temperature & corrosion resistance, low blister and stoning potential. These advantages can prevent liquid glass from pollution effectively.
Features of fused cast high zirconia brick
--excellent high temperature & corrosion resistance
--low blister and stoning potential
--high purity raw materials
--wide application in glass industry,ceramic fiber industry and construction field,etc.
Application field of fused cast high zirconia brick
1.Fused cast high zirconia brick has wide application in a wide range of super high temperature furnaces and kilns in military industry,science research, high melting point Metallurgical, laser crystal and electronic,etc.
2.For high quality and special glass furnaces such as TV glass, Borosilicate glass, Alumina silicate glass, Halogen lighting glass, Opal glass and Fiber glass.
3.Fused cast high zirconia brick mainly consists of HT-Z88-WS and HT-Z95-WS, and are used in sidewall, throat cover, throat support, electrode brick, dam brick parts.
Specification of Fused Cast High Zirconia Brick
| Item | TY-Z88-WS | TY-Z95-WS | ||
| Chemical Composition % | ZrO2 | ≥ | 89.00 | 93.60 |
| SiO2 | ≤ | 9.00 | 5.30 | |
| Al2O3 | ≤ | 1.00 | 1.00 | |
| Na2O | ≤ | 0.05 | 0.51 | |
| Others | ≤ | 1.60 | 1.0 | |
| Mineral Composition % | Baddeleyite | Typical | 89 | 94 |
| Glass Phase | 11 | 6 | ||
| Physical Properties | Cold Crushing Strength (MPa) | ≥ | 400 | 400 |
| Bulk Density (g/cm³) | Typical | 5.10 | 5.30 | |
| Liner Thermal Expansion (%) | 1000℃ | 0.65 | 0.70 | |
| 1500℃ | 0.10 | 0.30 | ||
Packing of Fused Cast High Zirconia Brick
1.on wooden pallets with plastic cover: wooden pallet size :930*930 or 1000*1000mm,
2.Load weight of each pallet: 1.5-2.0 tons,
3.230*114*65mm:512PCS/Pallet, 230*114*75mm:448PCS/Pallet.
Shipping of Fused Cast High Zirconia Brick
1.Our packaging is as per customer’s request
2.Normal goods delivered by sea transport
3.Sample shipping by express
4.We will shipping and delivery goods timely, quanlity and quantity guaranteed, and also in accordance with the contract and customer's requirment completely.
