L1960xw1550xh1600mm Polyurethane Dispensing Machine for LED Bar Light Manufacturing
Price:
$9,900.00/sets 1-1 sets
MOQ:
Negotiable
Delivery Time:
Negotiable
Brand:
Daheng
Product Description
Polyurethane glue resin metering dispensing machine
1. Working Area: controlled by manual 2.Application products: Multi-purpose, such as small products, Power supply, LED driver, Capacitor; transformer, sensor etc. 3.High precision valve: high speed, glue off clean, no glue drawing, no dropping. 4. Gear pump special for transparent glue. 5. Mix glue A & B more evenly; no more or no less for agent B.
Parameter
Adjustable ratio | 1 ：1 ---10：1 | Flow control | Digital input |
Output speed | 0.5g/s --24g/s base on ratio | ||
Automatic control system | Touch screen/ trigger switch/third party signal | Parameter display | Pipe pressure , glue temperature and parameter can be transmitted to third party device through communication module |
Viscosity | 300cps~50000cps（reference value） | Mixed mode | Dynamic mixing (automatic detect function) |
Operation mode | Manual/automatic | Ratio control | PLC/Daheng pumps |
Glue tank | Stainless tank A（40L）and stainless tank B(25L）, No machine stop when material feeding | Vacuum defoamation（-0.1MPa），4L/s | Liquid level sensor (low liquid level /high liquid level and limit liquid level) |
Mixing accuracy | ≤±2% | Voltage | 220V/50Hz/1500W |
Input air pressure | 0.4MPa—0.7MPa | Material | SPCC+Industrial aluminium+stainless +metal plate |
