RoHS Certified Evonic Waterproof Dustproof IP54 40KW 100A Fast DC Wall-Mounted Electric Vehicles Charging Station with 5m Cable
Price:
$3,900.00-4,200.00/pieces
MOQ:
2 pieces
Delivery Time:
Negotiable
Brand:
/
Product Description
Details Images





Product Description
Standard | DC EV Charger 7KW/20KW/40KW/120KW |
Operation Voltage | DC 200-750V(optional) |
Insulation Resistance | >1000MN(DC 500V) |
Withstand Voltage | 2000V |
Pin Material | Copper Alloy, Silver Plating |
Shell Material | Thermoplastic,Flame Retardant Grade UL94 V-0 |
Mechanical Life | No-Load Plug In /Pull Out > 10000 Times |
Contact Resistance | 0.5mΩ Max |
Terminal Temperature Rise | <50K |
Operating Temperature | -30°C~+50℃ |
Impact Insertion Force | >300N |
Waterproof Degree | IP54 |
Cable Protection | Reliability of materials,antiflaming.pressure-resistantabrasion resistance,impact resistance and high oil |
Certification | TUV,ULCE Approved |
