High Lighting SMD LED Sports Lights 600W Sport Court Lighting For Stadium
Product Features
1. Integrated die casting heat sink: Excellent thermal management & compact structure.
2. Die-casting aluminum arm &bracket:Anti-typhoon 17 & High corrosion resistance for coastal area.
3. Integrated breather valve: Balance the internal & external temperature and humidity
4. Spill shield: Reduce light pollution.
5. Racked angle: Allows for precise installation.
6. Double surge protection: Driver & extra 10KV SPD.
7. Top brand LED chip and driver, ensure the product quality and lifetime.
8. Optical lighting distributions: 10°, 25°, 45°, 60°, 90°.
9. High luminous efficacy: 160lm/W.
10. Ingress protection & Impact protection rating: IP66 & IK08
| Model | YXR-QC-600W-E |
| Power | 600W |
| Lumens(lm) | 90000 |
| Other Power Options | 300W/400W/500W/800W/1000W/1200W/1600W/1800W |
| Weight(kg) | 17.4 |
| Sizes(mm) | 592*509*423 |
| Efficacy | 150lm/W |
| CCT | 2700-6500K |
| CRI | ≥70Ra |
| LED Chips | Lumileds 3030 |
| PF | >0.97 |
| Input Voltage | AC100-277V(Moso) |
| Beam Angle | 15°/30°/45°/60° |
| Work Temp | -35~55℃ |
| Humidity | 15%~90% RH, no condensing |
| Finish | Sprayed with outdoor special powder |
| Life Span | ≥50,000 Hrs (LM80 @ 35℃ ) |
| IP Grade | IP66 |
| IK Grade | IK08 |
| Body material | PC lens + Aluminum housing |
| Power Wire | Rubber cable(3*1mm²) L=0.3m |
| Electronic safety grade | Class I |
Outdoor sports arena, Outdoor venues, Football field, Tennis court, Hockey field, Rugby pitch, Riding arena, Volleyball court, Outdoor water polo, Training pitch,Training fields, Backyard lighting, Ski resorts, Parking lot, Parking squares and other outdoor lighting places.
