Outdoor Led Advertising Screen Outdoor Led Screen Full Color P4 Outdoor Led Screen
Price:
Negotiable
MOQ:
1SET
Delivery Time:
7-15work days
Brand:
HSCXLED
Product Description
P4 LED display for Outdoor Advertising
Led Billboard Digital Board Advertising display/Outdoor Fixed LED Screen
Outdoor LED Display for Commercial Video Advertising
Full Color Outdoor Led Display Screen/Outdoor Led Display Screen
Outdoor LED Display Features:
Certified IP65 waterproof and dustproof protection ensures reliable, 7680Hz Refresh Rate, 5000+ Nits Brightness.
Brightness up to 5000-8,000 nits ensures crystal-clear visuals even under direct sunlight, maximizing advertising impact and audience reach throughout the day.
Advanced common cathode design reduces power consumption by 30%, significantly lowering long-term operational costs and extending the display's working lifespan.
Supports both front and rear maintenance, allowing for quick component replacement and flexible installation on building facades or high-rise poles.
High-quality aluminum cabinets provide excellent heat dissipation without noisy fans, ensuring stable operation and durability in high-temperature outdoor climates.
Outdoor Led Advertising Screen Parameter:
| Parameter | P2.5 | P3.07 | P4 | P5 | P6 |
| LED Type | SMD1415 | SMD1415 | SMD1921 | SMD1921 | SMD3535 |
| Pixel Pitch | 2.5mm | 3.07mm | 4mm | 5mm | 6.6mm |
| Pixel Density | 160000 dots/m² | 105625 dots/m² | 62500 dots/m² | 40000 dots/m² | 22500 dots/m² |
| Module Dimension (W×H×D) | 320*160*14.5mm | 320*160*14.5mm | 320*160*14.5mm | 320*160*14.5mm | 320*160*14.5mm |
| Cabinet Dimension (W×H×D) | 960*960*90mm | 960*960*90mm | 960*960*90mm | 960*960*90mm | 960*960*90mm |
| Cabinet Resolution | 384*384 dots | 312*312 dots | 240*240 dots | 192*192 dots | 145*145 dots |
| Cabinet Weight | 25 kg | 25 kg | 25 kg | 25 kg | 25 kg |
| Panel Material | Sheet Metal | Sheet Metal | Sheet Metal | Sheet Metal | Sheet Metal |
| Refresh Rate | ≥3840Hz | ≥3840Hz | ≥3840Hz | ≥3840Hz | ≥3840Hz |
| Brightness | 5000 cd/m² | 5000 cd/m² | 5000 cd/m² | 5000 cd/m² | 5000 cd/m² |
| Gray Scale | 14 Bit | 14 Bit | 14 Bit | 14 Bit | 14 Bit |
| Color Temperature | 3000~15000K | 3000~15000K | 3000~15000K | 3000~15000K | 3000~15000K |
| Viewing Angle (H/V) | 160°/140° | 160°/140° | 160°/140° | 160°/140° | 160°/140° |
| Optimum Viewing Distance | ≥2.5 m | ≥3m | ≥4m | ≥5m | ≥6m |
| Contrast Ratio | 6000:01:00 | 6000:01:00 | 6000:01:00 | 6000:01:00 | 6000:01:00 |
| Scan Mode | 1/32 scan | 1/13 scan | 1/10 scan | 1/8 scan | 1/6 scan |
| IP Rating | IP65 | IP65 | IP65 | IP65 | IP65 |
| Power Consumption (Avg.) | 220 W/m² | 220 W/m² | 220 W/m² | 220 W/m² | 220 W/m² |
| Input Voltage | AC100~240V (50/60Hz) | AC100~240V (50/60Hz) | AC100~240V (50/60Hz) | AC100~240V (50/60Hz) | AC100~240V (50/60Hz) |
| Operating Temperature | -20°C to 60°C | -20°C to 60°C | -20°C to 60°C | -20°C to 60°C | -20°C to 60°C |
| Operating Humidity | 10% - 90% RH | 10% - 90% RH | 10% - 90% RH | 10% - 90% RH | 10% - 90% RH |
| Storage Temperature | -20°C to 60°C | -20°C to 60°C | -20°C to 60°C | -20°C to 60°C | -20°C to 60°C |
| Storage Humidity | 10% - 65% RH | 10% - 65% RH | 10% - 65% RH | 10% - 65% RH | 10% - 65% RH |
| Maintenance | Front & Rear | Front & Rear | Front & Rear | Front & Rear | Front & Rear |
| LED Lifetime | 100000 Hours | 100000 Hours | 100000 Hours | 100000 Hours | 100000 Hours |
| Control system | NOVA/Colorlight | NOVA/Colorlight | NOVA/Colorlight | NOVA/Colorlight | NOVA/Colorlight |
| Application | Outdoor | Outdoor | Outdoor | Outdoor | Outdoor |
| Maintenance method | Rear(Front optional) | Rear(Front optional) | Rear(Front optional) | Rear(Front optional) | Rear(Front optional) |
| Type | LED | LED | LED | LED | LED |
Outdoor Advertising LED Display Advantages:
High Definition & Clarity:
Outdoor HD led display screen- small pixel pitch delivers sharp text, detailed images, and smooth video; ideal for mid-to-long viewing distance (≥4m) with balanced resolution and cost.
Superior Visibility:
Our outdoor led screens have 5,500–8,000 nits high brightness with anti-glare design ensures readability under direct sunlight;and the led screens auto-brightness adjustment optimizes contrast day/night.
Stable & Smooth Visuals:
High refresh rate (≥3,840Hz, up to 7,680Hz) eliminates flicker; >5,000:1 contrast ratio for vivid colors and deep blacks, enhancing outdoor advertising screen impact.
Wide Viewing Angle:
140°–170° horizontal/vertical viewing ensures consistent image quality from almost any angle, Outdoor Advertising LED Display maximizing audience reach.
Energy-Saving & Durable:
The Outdoor Advertising LED Display Low power consumption (200–300W/㎡) cuts electricity costs by up to 30%; long lifespan (80,000–100,000 hours) for 24/7 operation.
Weatherproof & Reliable:
IP65 front/IP54 rear protection against rain, dust, and extreme temperatures; Our Outdoor Advertising LED Display die-cast aluminum cabinet for stability, heat dissipation, and long service life.
Flexible & Easy to Use:
Modular design supports custom sizes/shapes; simple installation, HSCXLED-Outdoor Advertising LED Display support front/rear maintenance, and fast content updates via Wi‑Fi/4G/LAN.
Safe & Stable:
Our outdoor high-definition LED advertising display screen adopts a high protection level design,Low-voltage DC power supply; anti-lightning, anti-static, and anti-electromagnetic interference for uninterrupted outdoor use.
H&S led displays:
1. Wide application field & short ROI time:
commercial advertising LED display screen, Stadium perimeter LED display screen, Mobile trailer LED display screen for mobile media,shopping mall LED display screen for logo showing, bank&stock exchange LED display screen for rates showing, train & bus station LED display screen,air port LED display screen, telecommunication LED display screen system for information showing and instruction .
2. High Contrast ratio: 4000:1
Which is a very high level to ensure a vivid image of our LED display screen system.
3. First-class LED chip:
Supplied by Nichia of Japan & other high strictly selected LED chip to ensure the long lifetime and high brightness of our LED display screen system
4. Clear vivid image quality:
Even in direct, full-on sunlight to ensure you attract more audience to get short ROI of your LED display screen's investment.
