Electric V-type ball valve is the execution unit in the electric unit combination instrument, which can realize proportional adjustment, receive ON-OFF or 4-20mAC or 1-5VDC signal for proportional action of small, strong, high-precision electric actuator, sensitive action, and adopt direct indication and feedback of corner. Switch type only need to input single-phase power supply to control the operation, to achieve the adjustment of pressure, flow, temperature, liquid level and other parameters. There is a V-shaped incision on the spool, which is rotated relative to the hard-sealed valve to generate shear force, which can cut off the fiber and prevent stuck. It is especially suitable for the adjustment of mud and medium containing fiber, as well as medium containing small solid suspended matter.

The excellent adjustment performance of electric V-type ball valve makes the products widely used in petrochemical industry, fine chemical industry, paper making, metallurgy, sewage treatment, boiler water supply and other industrial fields of high-precision adjustment links. The medium flow in the pipeline is adjusted and cut off to achieve the production process according to certain specifications.
