4K60 Video Wall Controller with 1 into 6 Out HDMI Video Processor and Low Power Conduction Cooling
Price:
$165-226
MOQ:
1
Delivery Time:
5-8 days
Brand:
Bitvisus
Product Description
4K60 Video Wall Controller with Low Power Conduction Cooling
The BIT-VWC-106 is an advanced Ultra HD video wall controller from Bitvisus, featuring 1 HDMI/DP input and 6 HDMI outputs. This compact device enables flexible display configurations for store advertising, exhibitions, and professional display applications.
Key Features
- 1 into 6 out configuration for versatile screen arrangements
- Supports multiple splicing modes: horizontal, vertical, and field shape layouts
- Input resolution up to 3840x2400@60Hz with backward compatibility
- Output supports 180° rotation of the first line
- No stretching, distortion, or compression - maintains picture clarity
- Single display mode (1x1) support
- Multiple control options: pushbutton, infrared remote, and RS232 serial port
- Low power consumption with internal conduction cooling - no external cooling required
- Compatible with computers, Android boxes, game consoles, and other input sources
- 40nm process high-end programmable FPGA chip for ultra-fast processing without delays
Technical Specifications
| Product Name | BIT-VWC-106 |
| Input Interface | HDMI 2.0/DP 1.2, HDCP2.2 |
| Output Interface | HDMI 1.3 × 6 (≤15m) |
| Input Video Pixel Frequency | 600MHz |
| Output Video Pixel Frequency | 165MHz |
| Input Resolution | 2×3: 5760×2160@30Hz 3×2: 3840×3240@30Hz 5×1: 1920×5400@30Hz 6×1: 1920×6480@30Hz |
| Output Resolution | 1920×1080@60Hz / 1920×1200@60Hz |
| Audio | HDMI follow out, 3.5mm audio splitter connector |
| Control Methods | Pushbutton, infrared remote control, RS232 serial port |
| Power Supply | DC 12V 2A |
| Power Consumption | 12W |
| Storage/Working Temperature | -10～50ºC / 0～50ºC |
| Package Weight | 1.6KG |
| Warranty | 3 Years |
Frequently Asked Questions
Why Choose Bitvisus?
- Our own warehouse ensures shipping within 48 hours after payment (excluding weekends and holidays)
- OEM/ODM services available for custom requirements
- Leading manufacturer in video wall controller technology
How to Order?
- Contact us via email, chat, or messaging platforms with your requirements
- We provide proforma invoice based on your order request
- After payment confirmation, goods are delivered promptly
Warranty & After-sales Service
- 12 months warranty with lifetime service support
- Return or exchange available for faulty, damaged, or incorrect models
Shipping & Payment
- Payment methods: T/T, Visa, PayPal, Western Union, L/C
- Shipping options: DHL, UPS, EMS, FedEx, Air freight, Sea freight
