SHANMON 388T New Backhoe Loader for Sale --Ideal for Earth Excavation, Material Handling and Site Leveling

SHANMON 388T Backhoe Loader--Efficient All-round, Quality Choice

一,Core Advantage: Multi-purpose, Excellent Performance

1,All-round operation, double the efficiency

Dual function of digging + loading: rated bucket capacity of 1m³ (loading) / 0.3m³ (digging), the maximum digging depth reaches 3.96m, the maximum digging radius of 5.79m, easy to cope with earthmoving excavation, material loading, site formation and other diversified scenarios.

High adaptability: front and rear four gears design, 36km/h driving speed, with 2280mm wheelbase and wide tyres (front wheel 14-17.5-16PR/rear wheel 19.5L-24-14PR), stable passage through complex terrain, efficient transit.

2,Strong power, durable and reliable

Weichai high-efficiency engine: equipped with WP4G110E220 engine, rated power of 82kW, maximum torque of 430N-m, low fuel consumption and high output, meets the National II emission standards, adapted to high-intensity operations.

CARRARO transmission system: synchronised mechanical shift gearbox + torque converter, smooth gear shifting,  stable power transmission, industry-leading durability.

3,Humanized design, convenient operation

Spacious driving space: cab height of 3100mm, wide vision, ergonomic control layout, more comfortable for long time operation.

Intelligent hydraulic system: 130L large-capacity hydraulic oil tank, to protect the needs of continuous operation; maximum unloading height of 2.807 metres, unloading distance of 900mm, precise control of the operating range.

4,Quality guarantee, durable

Branded core components: Weichai engine, CARRARO transmission and drive axle, the key components are all adopted by international famous brands, low failure rate, maintenance cost saving.

Ultra-strong structural design: the whole machine has an operating weight of 7820kg, a rated load of 2500kg, a maximum lifting force of 2500kg, and a high-strength steel body, which is impact-resistant and extends the service life by 30%.

5,Energy saving and economy, cost optimisation

Large-capacity fuel tank: fuel tank 130L, long-lasting range; hydraulic system independent design, energy consumption reduced by 15%, lower operating costs.

二,Full coverage of application scenarios

Construction: earthmoving, pit backfilling, building materials loading and unloading.

Agricultural renovation: ditch digging, farmland leveling, material transport.

Municipal maintenance: pipeline laying, road repair, greening construction.

三,choose SHANMON388T, one against many!

Cost saving: no need to switch equipment frequently, 40% increase in overall efficiency.

Space-saving: compact design (total length 7.6 metres, width 2.23 metres), flexible to adapt to narrow construction sites.

Save after-sales service: global joint warranty service system, 24-hour technical support, worry-free quality!
